Product Description:

Processor support: Supports 6th / 7th generation i3/i5/i7/Pentium/Celeron processor in LGA1151
Chipset: Intel H110 chipset
Memory support: 2 DDR4 dual-channel slots, supports DDR4 2133MHz memory
LAN: Supports Realtek 8105E/8111E 10/100Mbps
Audio: Realtek 662, 3 x Audio Jacks for 6 channel High Definition Audio

Back panel:
1 x PS/2 keyboard port, 1 x PS/2 mouse port, 1 x HDMI port,
1 x VGA port, 2 x USB 2.0 ports, 2 x USB 3.0 ports, 1 x RJ45 port,
1 x 3-in Audio port (Lin In/ Lin Out/ MIC In)

On-Board connectors:
1 x 24-pin ATX power connector, 1 x 4-pin ATX power connector,
4 x SATA 3.0 ports, 1 x speaker connector, 1 x front panel audio connector,
2 x USB 2.0 connectors, 1 x USB 3.0 connector, 1 x F_AUDIO connector,
1 x 4-pin CPU fan connector, 1 x SYS fan connector
Slots: 1 PCI Express x 16 slot
Warranty: 1 Year

Product Description:

Supported CPU: Intel Core i7-800/i5-700/i5-600/i3-500 series processors in LGA 1156
Chipset: Intel 55 Chipset
Memory supported: "2x240-pin DDR3 SD RAM slots memory up to 8GB supports dual- channel DDR3 1066/1333/ 1600MHz memory"
BIOS: EFII BIOS
I/O interface: 1 x HDMI port, 1 x VGA Port, 6 x USB 2.0 Port, Compatible with USB 1.1, 1 x Rj45 Port, 1 x 3-in-1 Audio (Line In/Line Out/Mic In)
Onboard interface: 1 x 24 pin ATX Power Connector, 1 x 4 Pin ATX 12V Power Connector, 2 x USB Connectors, Supports 4 x USB 2.0, 1 x Front Audio Connector, 1 x Front Panel Connector, 1 x Speaker Connector, 2 x Fan Connectors 3 x Serial ATA Connections Ports
Integrated LAN: With 10/100Mbps LAN
Expansion slot: 1 x PCI express x16 Slot. 1 x MSATA Port
Form factor: Micro-ATX

Package contents
H55 Motherboard
SATA cables
Driver disc
Warranty: 1 Year

Product Description:

CPU: Intel Core  i7-800/i5-700/i5-600/i3-500 series processors in LGA 1156
Chipset: Intel BD82HM55 PCH
Memory support:    2x240-pin DDR3 SD RAM slots Memory up to 8GB
supports dual-channel DDR3 1066/1333/ 1600MHz memory
BIOS: EFII BIOS
I/O interface: 1xPS/2 keyboard port 1xPS/2 mouse port 1xVGA 1xHDMI 4xUSB 2.0, compatible with USB 1.1 1xRJ45 1x3-in-1 audio port (Line In/Line Out/Mic In)
Onboard interface: 1x24-pin ATX power connector 1x4-pin ATX 12V power connector 2xUSB connectors, support 4xUSB 2.0 1xFront panel audio connector 1xFront panel  connector 1xClear CMOS header 1xCOM connector 1xBEEP connector 4xserial ATA connection ports
Integrated LAN: with 10/100Mbps LAN
Expansion slot: 1xPCI express x16 slot 1xPCI express x1
Warranty: 1 Year

Product Description:

Processor support: Intel Core® i7/i5/i3/processors in LGA 1150
Chipset :Intel® H81 Chipset
Memory support: 2xDDR3 dual-channel slots, DDR3 1066/1333/1600MHz
LAN: Realtek 8105E 100/1000 Mbps
Audio: Realtek 662 3xAudio Jacks for 6 channel HD Audio
Back panel: 1xUSB mouse/keyboard port, 1xVGA, 1xHDMI, 2xUSB 3.0 ports, 2xUSB 2.0 ports, 1xLAN port, 3xaudio jacks
On-Board connectors: 1xFront panel connector, 1xSpeaker connector, 1xFront panel audio connector, 1xUSB 2.0 connector, 4xSATA ports, 1x4-pin CPU fan connector, 1xSYS fan connector, 1x24-pin ATX power connector, 1x4-pin ATX 12V power connector, 1xClear CMOS header
Slots: 1 PCI Express x16 slot
Warranty: 1 Year

Product Description:

Supported CPU: Socket 775 Intel Core 2 Quad/ Core 2 Duo/ Pentium Series/ Celeron Series Processor North Bridge - Intel G41
Chipset: South Bridge - Intel 82801GB
Memory supported:     2 DDR2 dual-channel RAM slots, Memory up to 4GB, Supports DDR2 800/667MHz memory, 2 x DIMM Slots
BIOS: AMI BIOS
I/O Interface: 1 x PS/2 keyboard, 1x PS/2 mouse port, 1 x VGA Port, 4 x USB 2.0 ports, RJ45 LAN port, 1 x 3-in-1 audio jacks
Onboard interface: 1 x Front panel connector, 1 x Front audio connector, 1 x COM Connector, 2 x USB 2.0 Connectors, 4 x SATA Ports, 1 x IDE slot, 1 x 4 pin CPU fan connector, 1 x 24-pin ATX power connector, 1 x 4-pin ATX 12V power connector, 1 x clear CMOS header
Integrated LAN: Supports RTL8106E 10/100 Mbps Ethernet LAN
Expansion slot: 1 x PCI Express x16 slot
Form factor: Micro-ATX

Package contents
G41-D2  Motherboard
I/O Backplate
SATA Cable
Driver disc
Warranty: 1 Year

Product Description:

Supported CPU:     Intel Core 2 Quad/ Core 2 Duo/ Pentium Series/ Celeron Series Processor North Bridge - Intel G41
Chipset: South Bridge - Intel ICH7 Chipset
Memory supported: 2 DDR3 dual-channel RAM slots, Memory up to 8GB ( Double Bank RAM) Supports DDR3 800/1066MHz memory, 2 x DIMM Slots
BIOS: AMI BIOS
I/O Interface: 1 x PS/2 keyboard port, 1 x PS/2 mouse port, 1 xVGA Port, 1 xCOM port, 4 x USB 2.0 ports, RJ45 LAN port, 1 x 3-in-1 audio jacks
Onboard interface: 1 x Front panel connector,1 x Front audio connector, 2 x USB 2.0 Connector, 4 x SATA Ports, 1 x 1 IDE slot,1 x 4 pin CPU fan connector,
1 x 24-pin ATX power connector, 1 x SYS Fan Connector, 1 x 4-pin ATX 12V power connector, 1 x clear CMOS header
Integrated LAN: Supports RTL8105E 10/100 Mbps Ethernet LAN
Expansion slot: 1 PCI Express x16 slot, 1 PCI Slot
Form factor: Mirco-ATX

Package contents
G41-D3  Motherboard
I/O Backboard
SATA Cable
IDE Cable
Driver disc
Warranty: 1 Year

Product Description:

Processor: Supports Pentium 4-500 Series / 600 Series / Extreme Edition Series Pentium E Series /  Pentium D - 800 / 900 Series Celeron E Series / Celeron D / Celeron 400 Series
Chipset: Intel® 82 G965 / 946 GZ / ICH7 Chipsets
Memory support: 2  DDR2 dual-channel slots, Support DDR2 800 / 667 / 533 MHz memory
LAN: Supports Realtek 8105E10 / 100 Mbps
Audio: Realtek ALC662 Channel
Back panel: 1 x PS/2 mouse / keyboard port, 1 VGA, 1 x COM port,  4 x USB 2.0 ports, 1 x RJ45 port, 3 audio jacks
On-Board connectors: 1 x Front panel connector, 1 x speaker connector,  1 x Front audio connector,  2 x USB 2.0 Connector 4 x SATA Ports 1 x 4 pin CPU fan connector,
1 x 24-pin ATX power connector, 1 x 4-pin ATX 12V power connector, 1 x clear CMOS header
Slots: 1 PCI Express x16 slot, 1 PCI Express x1 slot
Warranty: 1 Year

CPU:
LGA775 for Intel® Core™ 2 Extreme, Core™ 2 Quad, Core™ 2 Duo, Pentium® Dual Core, Pentium® D, Pentium® 4,
Celeron® (Conroe-L) and next generation 45nm Yorkfield & Wolfdale Processors.
Compatible with all 1333/1066/800/533 MHz FSB CPUs
Supports Hyper-Threading Technology

Chipset: Intel® Q33 + ICH7
Super I/O: Winbond W83627DHG chip

Memory:
Dual Channel DDR2 memory technology
2 x DDR2 DIMM slots
Supports DDR2 800/667 non-ECC, un-buffered memory
Max. capacity of system memory 4GB

BIOS: Supports "Plug and Play"
Advanced power management

Graphics: Intel® Graphics Media Accelerator 3100
Pixel Shader 2.0, DirectX 9.0

Audio: Realtek ALC883
5.1 Channel

LAN: Realtek® RT8105S Ethernet Controller (10/100Mbit)

Expansion Slots: 1 x PCI Express x16 slot 2 x 2.2 PCI slots

Connector:  1 x 24-pin ATX power connector 1 x 4-pin ATX 12V power connector 1 x floppy connector
1 x IDE connector (for 2 PATA devices) 4 x SATA 3Gb/s connectors 1 x CPU fan connector 1 x system fan connector 1 x front panel connector 1 x front audio connector
1 x USB 2.0 header for additional 2 USB 2.0 ports (by cables)

Rear Panel I/O: 1 x PS/2 Mouse Port 1 x PS/2 Keyboard Port 1 x Serial Port 1 x Parallel Port 1 x VGA Port 4 x Ready-to-Use USB 2.0 Ports 1 x RJ-45 LAN Port
HD Audio Jack: Line in / Front Speaker / Microphone

Support CD: Drivers

Accessories
Quick Installation Guide, I/O Shield
1 x ATA 100 Cable
1 x SATA Data Cable
Warranty: 1 Year

Product Description:

Supported CPU: Intel i7/i5/i3 series processors
Chipset: Intel B75 chipset
Memory supported: 2 DDR3 Dual channel RAM slots memory, up to 8GB, supports DDR3 1066/1333/ 1600MHz memory
BIOS: EFII Bios
I/O interface: 1 x HDMI Port, 1 x VGA Port, 4 x USB 2.0 Port, 2 x USB 3.0 Port 1 x RJ45 Port, 1 x 3-in-1 Audio
Onboard interface: 1 x 24 pin ATX power connector, 1 x 4 Pin ATX 12V power connector, 2 x SATA 2.0 Gb/s connectors, 2 x SATA 3.0 Gb/s connectors, 1 x USB 2.0 Header, 1 x USB 3.0 Header, 1 x Front audio connector, 1 x Front panel connector, 1 x Speaker connector, 2 x Fan connectors
Integrated LAN: 10/100 Mbps LAN
Expansion slot: 1 x PCI Express x16 slot, 1 x PCI Express x1 slot
Form factor: Micro-ATX

Package contents
ZEB-B75 Motherboard
SATA cable
I/O backboard
Driver disc
Warranty: 1 Year

Product Description:

Processor support: Supports Intel® i7/i5/i3/Pentium/Celeron processors in LGA1155
Chipset: Intel® H61Chipset
Memory support: 2  DDR3 dual-channel slots, Support DDR3 1066/1333/1600MHz memory
LAN: Supports Realtek 8105E/8111E 100/1000 Mbps
Audio: Realtek 662 3xAudio Jacks for 6 channel High definition audio
Back panel: 1 PS/2 mouse/keyboard port, 1 VGA port,  1HDMI  port, 4 USB 2.0 ports, 1 LAN port, 3 audio jacks
On-Board connectors: 1 x Front panel connector, 1 x speaker connector,  1 x Front panel audio connector (2 x 5pin),  4 x USB 2.0 ports, 4 x SATA 3Gb/s (SATAII) ports, 1 x 4pin CPU fan connector, 1 x SYS fan connector,  1 x 24-pin ATX power connector, 1 x 4-pin  ATX  12V power connector, 1 x 3pin clear  CMOS header
Slots: 1 PCI Express x16 slot, 1 PCI Express x1 slot

Package Contents
Motherboard - 1no
Back plate - 1no
SATA cable - 2nos
User manual - 1no
Driver CD - 1no
Warranty: 1 Year

• Nvidia MCP61P chipset
• Support AM2,AM2+ and AM3 socket, 940 series processor
• 533/667/800MHZ FSB bus frequency
• Support 1xDDR2 or 1xDDR3 Memory
• 4xUSB 2.0
• 1XPCI Express X8, 1 PCI slot, 2 SATA, 1 IDE
• 10/100 LAN
• 6 channel sound output
• VGA port, COM port
• Warranty: 1 Year

Product Description:

Supported CPU: Intel Core 2 Duo/ Pentium D/ Celeron D/ Celeron series Processor
Chipset: North Bridge-Intel 945G/GC/GZChipset South Bridge-IntelICH7Chipset
Memory supported: DDR2 400/533/667/800 MHz SDRAM (4GB Max) 2 x DIMM Slots
BIOS: AMI BIOS
I/O Interface: 1 x PS/2 keyboard port, 1 x PS/2 mouse port,1 x VGA Port, 1 x COM port, 4 x USB 2.0 ports, RJ45 LAN port, 1 x 3-in-1 audio jacks
Onboard interface: 1 x Front panel connector,1 x Front audio connector, 1 x Speaker Connector ,2 x USB 2.0 Connectors, 4 x SATA Ports,1 x IDE slot,1 x CPU fan connector, 1 x 24-pin ATX power connector, 1 x 4-pin ATX 12V power connector, 1 x SYS Fan Connector, 1 x clear CMOS header
Integrated LAN: Supports Realtek 8105E 10/100 Mbps Ethernet LAN
Expansion slot: 1 PCI Express x16 slot, 1 PCI Slot
Form factor: Micro-ATX

Package contents
945 Motherboard
SATA Cable
I/O Backboard
IDE Cable
Driver disc
Warranty: 1 Year
