Hp Showroom in Hyderabad - Synology Storage
CPU :
CPU Model : Intel Xeon Silver 4110 x 2
CPU Architecture : 64-bit
CPU Frequency : 8-Core 2.1 (base) / 3.0 (turbo) GHz
Hardware Encryption Engine (AES-NI) : Yes
Memory :
System Memory : 32GB DDR4 ECC RDIMM
Memory Module Pre-installed : 32 GB (16 GB x 2)
Total Memory Slots : 16
Memory Expandable up to : 512 GB (32 GB x 16)
Storage :
Drive Bays : 24
Maximum Drive Bays with Expansion Unit : 48 (RX1217sas) / 72 (RX2417sas)
Compatible Drive Type* (See all supported drives)
2.5" SAS HDD
2.5" SAS SSD
2.5" SATA SSD
Maximum Internal Raw Capacity : 184.32 TB (7.68 TB drive x 24) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units : 568.32 TB (184.32 TB + 16 TB drive x 24) (Capacity may vary by RAID types)
Maximum Single Volume Size*
200 TB (for RAID 5 or RAID 6 groups only)
108 TB
Hot Swappable Drive : Yes
External Ports :
RJ-45 1GbE LAN Port : 2 (with Link Aggregation / Failover support)
RJ-45 10GbE LAN Port : 2 (with Link Aggregation / Failover support)
USB 3.0 Port : 2
Expansion Port : 1
PCIe
PCIe Expansion : 2 x Gen3 x8 slots (x8 link)
Add-In-Card Support : PCIe Network Interface Card (Learn more)
File System :
Internal Drives :
Btrfs
EXT4
External Drives :
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Form Factor (RU) : 2U
Size (Height x Width x Depth) : 88 mm x 482 mm x 724 mm
Weight : 17.26 kg
Rack Installation Support* : 4-post 19" rack (Synology Rail Kit - RKS1317)
Notes
The rail kit is sold separately
Others :
System Fan : 80 mm x 80 mm x 4 pcs
Fan Speed Mode :
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan : Yes
Power Recovery : Yes
Noise Level* : 53.7 dB(A)
Scheduled Power On / Off : Yes
Wake on LAN / WAN : Yes
Power Supply Unit / Adapter : 800 W
Redundant Power Supply : Yes
AC Input Power Voltage : 100 V to 240 V AC
Power Frequency : 50/60 Hz, Single Phase
Power Consumption*
288.49 W (Access)
145.8 W (HDD Hibernation)
Temperature :
Operating Temperature : 0°C to 35°C (32°F to 95°F)
Storage Temperature : -20°C to 60°C (-5°F to 140°F)
Relative Humidity : 5% to 95% RH
Warranty: 5 Years
CPU :
CPU Model : Intel Xeon D-1541
CPU Architecture : 64-bit
CPU Frequency : 8-Core 2.1 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI) : Yes
Memory :
System Memory : 16 GB DDR4 ECC RDIMM
Memory Module Pre-installed : 16 GB (16 GB x 1)
Total Memory Slots : 4
Memory Expandable up to : 128 GB (32 GB x 4)
Storage :
Drive Bays : 24
Maximum Drive Bays with Expansion Unit : 48 (RX1217sas) / 72 (RX2417sas)
Compatible Drive Type* (See all supported drives) :
2.5" SAS HDD
2.5" SAS SSD
2.5" SATA SSD
Maximum Internal Raw Capacity : 368.44 TB (15.36 TB drive x 24) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units :1,105.92 TB (368.44 TB + 15.36 TB drive x 48) (Capacity may vary by RAID types)
Maximum Single Volume Size*
200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)
108 TB
Hot Swappable Drive : Yes
External Ports :
RJ-45 1GbE LAN Port : 4 (with Link Aggregation / Failover support)
RJ-45 10GbE LAN Port : 2 (with Link Aggregation / Failover support)
USB 3.0 Port : 2
Expansion Port : 1
PCIe :
PCIe Expansion : 1 x Gen3 x8 slot (x8 link)
Add-In-Card Support : PCIe Network Interface Card (Learn more)
File System :
Internal Drives :
Btrfs
EXT4
External Drives :
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Appearance :
Form Factor (RU) : 2U
Size (Height x Width x Depth) : 88 mm x 482 mm x 724 mm
Weight : 14.9 kg
Rack Installation Support* : 4-post 19" rack (Synology Rail Kit - RKS1317)
Notes : The rail kit is sold separately
Others :
System Fan : 80 mm x 80 mm x 4 pcs
Fan Speed Mode :
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan : Yes
Power Recovery : Yes
Noise Level* : 57 dB(A)
Scheduled Power On / Off :Yes
Wake on LAN / WAN : Yes
Power Supply Unit / Adapter : 500 W
Redundant Power Supply : Yes
AC Input Power Voltage : 100 V to 240 V AC
Power Frequency : 50/60 Hz, Single Phase
Power Consumption* :
313.84 W (Access)
125.77 W (HDD Hibernation)
Warranty : 5Years
CPU
CPU Model : Intel Pentium D1508
CPU Architecture : 64-bit
CPU Frequency : Dual Core 2.2 (base) / 2.6 (turbo) GHz
Hardware Encryption Engine (AES-NI) :Yes
Memory :
System Memory : 8 GB DDR4 ECC SO-DIMM
Memory Module Pre-installed : 8 GB (8 GB x 1)
Total Memory Slots : 2
Memory Expandable up to : 32 GB (16 GB x 2)
Storage :
Drive Bays : 12
Maximum Drive Bays with Expansion Unit : 36
Compatible Drive Type* (See all supported drives) : 2.5" SATA SSD
Maximum Internal Raw Capacity : 92.16 TB (7.68 TB drive x 12) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units : 476.16 TB (92.16 TB + 16 TB drive x 24) (Capacity may vary by RAID types)
Maximum Single Volume Size*
200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)
108 TB
Hot Swappable Drive : Yes
External Ports :
RJ-45 1GbE LAN Port : 4 (with Link Aggregation / Failover support)
USB 3.0 Port : 3
Expansion Port : 2
PCIe :
PCIe Expansion : 1 x Gen3 x8 slot (x8 link)
Add-In-Card Support :
PCIe Network Interface Card (Learn more)
M2D18 - Dual M.2 SATA/NVMe SSD adapter card for SSD cache
File System :
Internal Drives :
Btrfs
EXT4
External Drives :
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Appearance :
Size (Height x Width x Depth) : 166 mm x 282 mm x 243 mm
Weight : 5.2 kg
Others:
System Fan : 92 mm x 92 mm x 2 pcs
Fan Speed Mode :
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan : Yes
Brightness Adjustable Front LED Indicators : Yes
Power Recovery : Yes
Noise Level* : 28.1 dB(A)
Scheduled Power On / Off : Yes
Wake on LAN / WAN : Yes
Power Supply Unit / Adapter : 250 W
AC Input Power Voltage : 100 V to 240 V AC
Power Frequency : 50/60 Hz, Single Phase
Power Consumption* :
107.92 W (Access)
48.36 W (HDD Hibernation)
British Thermal Unit :
368.45 BTU/hr (Access)
165.12 BTU/hr (HDD Hibernation)
Temperature :
Operating Temperature : 5°C to 40°C (40°F to 104°F)
Storage Temperature : -20°C to 60°C (-5°F to 140°F)
Relative Humidity: 5% to 95% RH
Warranty : 5 Years
CPU :
CPU Model : Intel Xeon D-1567
CPU Architecture : 64-bit
CPU Frequency : 12 Core 2.1 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI) : Yes
Memory :
System Memory : 16 GB DDR4 ECC RDIMM
Memory Module Pre-installed : 16 GB (16 GB x 1)
Total Memory Slots : 4
Memory Expandable up to : 128 GB (32 GB x 4)
Storage :
Drive Bays : 12
Maximum Drive Bays with Expansion Unit : 96 (RX1217sas) / 180 (RX2417sas)
Compatible Drive Type* (See all supported drives) :
3.5" SAS HDD
2.5" SAS HDD
2.5" SAS SSD
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity : 192 TB (16 TB drive x 12) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units : 1,536 TB (192 TB + 16 TB drive x 84) (Capacity may vary by RAID types)
Maximum Single Volume Size* :
200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)
108 TB
Hot Swappable Drive : Yes
External Ports :
RJ-45 1GbE LAN Port : 4 (with Link Aggregation / Failover support)
RJ-45 10GbE LAN Port: 2 (with Link Aggregation / Failover support)
USB 3.0 Port : 2
Expansion Port :1
PCIe :
PCIe Expansion : 2 x Gen3 x8 slots (x8 link)
Add-In-Card Support : PCIe Network Interface Card (Learn more)
File System :
Internal Drives :
Btrfs
EXT4
External Drives :
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes : exFAT Access is purchased separately in Package Center.
Appearance :
Form Factor (RU) : 2U
Size (Height x Width x Depth) : 88 mm x 482 mm x 724 mm
Weight : 14.5 kg
Rack Installation Support* : 4-post 19" rack (Synology Rail Kit - RKS1317)
Notes : The rail kit is sold separately
Others :
System Fan : 80 mm x 80 mm x 4 pcs
Fan Speed Mode :
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan : Yes
Power Recovery : Yes
Noise Level* : 49.8 dB(A)
Scheduled Power On / Off : Yes
Wake on LAN / WAN :Yes
Power Supply Unit / Adapter : 500 W
Redundant Power Supply : Yes
AC Input Power Voltage: 100 V to 240 V AC
Power Frequency : 50/60 Hz, Single Phase
Power Consumption* :
156.23 W (Access)
72.37 W (HDD Hibernation)
British Thermal Unit :
533.08 BTU/hr (Access)
246.94 BTU/hr (HDD Hibernation)
Temperature :
Operating Temperature : 0°C to 35°C (32°F to 95°F)
Storage Temperature : -20°C to 60°C (-5°F to 140°F)
Relative Humidity : 5% to 95% RH
Warranty : 5 Years
CPU :
CPU Model : Intel Xeon D-1541
CPU Architecture : 64-bit
CPU Frequency : 8-Core 2.1 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI) : Yes
Memory :
System Memory : 16 GB DDR4 ECC RDIMM
Memory Module Pre-installed : 16 GB (16 GB x 1)
Total Memory Slots : 4
Memory Expandable up to : 128 GB (32 GB x 4)
Storage :
Drive Bays : 12
Maximum Drive Bays with Expansion Unit : 96 (RX1217sas) / 180 (RX2417sas)
Compatible Drive Type* (See all supported drives) :
3.5" SAS HDD
2.5" SAS HDD
2.5" SAS SSD
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity : 192 TB (16 TB drive x 12) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units : 1,536 TB (192 TB + 16 TB drive x 84) (Capacity may vary by RAID types)
Maximum Single Volume Size* :
200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)
108 TB
Hot Swappable Drive : Yes
External Ports :
RJ-45 1GbE LAN Port : 4 (with Link Aggregation / Failover support)
RJ-45 10GbE LAN Port : 2 (with Link Aggregation / Failover support)
USB 3.0 Port : 2
Expansion Port : 1
PCIe :
PCIe Expansion : 2 x Gen3 x8 slots (x8 link)
Add-In-Card Support : PCIe Network Interface Card (Learn more)
File System :
Internal Drives :
Btrfs
EXT4
External Drives :
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes : exFAT Access is purchased separately in Package Center.
Appearance :
Form Factor (RU) : 2U
Size (Height x Width x Depth) : 88 mm x 482 mm x 724 mm
Weight : 14.5 kg
Rack Installation Support* :4-post 19" rack (Synology Rail Kit - RKS1317)
Notes : The rail kit is sold separately
Others :
System Fan : 80 mm x 80 mm x 4 pcs
Fan Speed Mode :
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan : Yes
Power Recovery : Yes
Noise Level* : 49.8 dB(A)
Scheduled Power On / Off : Yes
Wake on LAN / WAN : Yes
Power Supply Unit / Adapter : 500 W
Redundant Power Supply : Yes
AC Input Power Voltage : 100 V to 240 V AC
Power Frequency : 50/60 Hz, Single Phase
Power Consumption* :
137.17 W (Access)
70.95 W (HDD Hibernation)
British Thermal Unit :
468.04 BTU/hr (Access)
242.09 BTU/hr (HDD Hibernation)
Temperature :
Operating Temperature : 0°C to 35°C (32°F to 95°F)
Storage Temperature : -20°C to 60°C (-5°F to 140°F)
Relative Humidity : 5% to 95% RH
Warranty : 5 Years
Controller :
Number of Controller Module : 2
CPU :
CPU Model : Intel Xeon D-1521
CPU Quantity (per controller) : 1
CPU Architecture : 64-bit
CPU Frequency : Quad Core 2.4 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI) : Yes
Memory :
System Memory (per controller) : 8 GB DDR4 ECC UDIMM
Pre-installed Memory Module (per controller) : 8 GB (8 GB x 1)
Total Memory Slots (per controller) : 4
Expandable Memory (per controller): 64 GB (16 GB x 4)
Storage :
Drive Bays : 12
Maximum Drive Bays with Expansion Unit : 36 (RXD1219sas)
Compatible Drive Type* (See all supported drives) :
3.5" SAS HDD
2.5" SAS HDD
2.5" SAS SSD
Maximum Internal Raw Capacity : 192 TB (16 TB drive x 12) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units : 576 TB (192 TB + 16 TB drive x 24) (Capacity may vary by RAID types)
Maximum Single Volume Size* :
200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)
108 TB
Hot Swappable Drive : Yes
External Ports :
RJ-45 1GbE LAN Port (per controller) : 2 (with Link Aggregation / Failover support)
RJ-45 10GbE LAN Port (per controller) : 1
Expansion Port : 1
PCIe :
PCIe Expansion (per controller) : 1 x Gen3 x8 slot (x8 link)
Add-In-Card Support : PCIe Network Interface Card (Learn more)
File System :
Internal Drives :
Btrfs
EXT4
Appearance :
Form Factor (RU) : 2U
Size (Height x Width x Depth) : 88 mm x 430.5 mm x 692 mm
Size (Height x Width x Depth) (with server ears) : 88 mm x 482 mm x 724 mm
Weight : 19.7 kg
Rack Installation Support* : 4-post 19" rack (Synology Rail Kit - RKS1317)
Notes : The rail kit is sold separately
Others :
System Fan : 60 mm x 60 mm x 2 pcs
Fan Speed Mode :
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan : Yes
Power Recovery : Yes
Noise Level* : 51.3 dB(A)
Power Supply Unit / Adapter : 500 W
Redundant Power Supply : Yes
AC Input Power Voltage: 100 V to 240 V AC
Power Frequency : 50/60 Hz, Single Phase
Power Consumption* :
417.48 W (Access)
274.38 W (HDD Hibernation)
British Thermal Unit :
1425.45 BTU/hr (Access)
936.85 BTU/hr (HDD Hibernation)
Temperature :
Operating Temperature : 0°C to 35°C (32°F to 95°F)
Storage Temperature : -20°C to 60°C (-5°F to 140°F)
Relative Humidity : 5% to 95% RH
Warranty : 5 Years
CPU :
CPU Model : Intel Xeon D-1541
CPU Architecture : 64-bit
CPU Frequency : 8-Core 2.1 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI) : Yes
Memory :
System Memory : 8 GB DDR4 ECC UDIMM
Memory Module Pre-installed : 8 GB (8 GB x 1)
Total Memory Slots : 4
Memory Expandable up to : 64 GB (16 GB x 4)
Storage :
Drive Bays : 16
Maximum Drive Bays with Expansion Unit : 40
Compatible Drive Type* (See all supported drives) :
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity : 256 TB (16 TB drive x 16) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units : 640 TB (256 TB + 16 TB drive x 24) (Capacity may vary by RAID types)
Maximum Single Volume Size* :
200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)
108 TB
Hot Swappable Drive : Yes
External Ports :
RJ-45 1GbE LAN Port : 4 (with Link Aggregation / Failover support)
RJ-45 10GbE LAN Port : 2 (with Link Aggregation / Failover support)
USB 3.0 Port : 2
Expansion Port : 2
PCIe :
PCIe Expansion : 2 x Gen3 x8 slots (x8 link)
Add-In-Card Support : PCIe Network Interface Card (Learn more)
M2D18 - Dual M.2 SATA SSD adapter card for SSD cache
Notes : RS4017xs+ with M2D18 can only support M.2 SATA SSD. M.2 NVMe/AHCI PCIe SSD is not supported.
File System :
Internal Drives :
Btrfs
EXT4
External Drives :
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes : exFAT Access is purchased separately in Package Center.
Appearance :
Form Factor (RU) : 3U
Size (Height x Width x Depth) : 132.3 mm x 482 mm x 656.5 mm
Weight : 17.4 kg
Rack Installation Support* : 4-post 19" rack (Synology Rail Kit - RKS1317)
Notes : The rail kit is sold separately
Others :
System Fan : 80 mm x 80 mm x 3 pcs
Fan Speed Mode :
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan : Yes
Power Recovery : Yes
Noise Level* : 44.7 dB(A)
Scheduled Power On / Off : Yes
Wake on LAN / WAN : Yes
Power Supply Unit / Adapter : 800 W
Redundant Power Supply : Yes
AC Input Power Voltage : 100 V to 240 V AC
Power Frequency : 50/60 Hz, Single Phase
Power Consumption* :
136.4 W (Access)
69.2 W (HDD Hibernation)
British Thermal Unit :
465.7 BTU/hr (Access)
236.3 BTU/hr (HDD Hibernation)
Temperature :
Operating Temperature : 5°C to 35°C (40°F to 95°F)
Storage Temperature : -20°C to 60°C (-5°F to 140°F)
Relative Humidity : 5% to 95% RH
Warranty : 5 Years
CPU :
CPU Model : Intel Xeon D-1531
CPU Architecture : 64-bit
CPU Frequency : 6-Core 2.2 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI) : Yes
Memory :
System Memory : 8 GB DDR4 ECC UDIMM
Memory Module Pre-installed : 8 GB (8 GB x 1)
Total Memory Slots : 4
Memory Expandable up to : 64 GB (16 GB x 4)
Storage :
Drive Bays : 12
Maximum Drive Bays with Expansion Unit : 36
Compatible Drive Type* (See all supported drives) :
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity : 192 TB (16 TB drive x 12) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units : 576 TB (192 TB + 16 TB drive x 24) (Capacity may vary by RAID types)
Maximum Single Volume Size* :
200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)
108 TB
Hot Swappable Drive : Yes
External Ports :
RJ-45 1GbE LAN Port : 4 (with Link Aggregation / Failover support)
RJ-45 10GbE LAN Port : 2 (with Link Aggregation / Failover support)
USB 3.0 Port : 2
Expansion Port :2
PCIe :
PCIe Expansion : 2 x Gen3 x8 slots (x8 link)
Add-In-Card Support :
PCIe Network Interface Card (Learn more)
M2D18 - Dual M.2 SATA SSD adapter card for SSD cache
Notes : RS3617xs+ with M2D18 can only support M.2 SATA SSD. M.2 NVMe/AHCI PCIe SSD is not supported.
File System :
Internal Drives:
Btrfs
EXT4
External Drives :
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes : exFAT Access is purchased separately in Package Center.
Appearance :
Form Factor (RU) : 2U
Size (Height x Width x Depth) : 88 mm x 482 mm x 724 mm
Weight : 14.5 kg
Rack Installation Support* : 4-post 19" rack (Synology Rail Kit - RKS1317)
Notes : The rail kit is sold separately
Others :
System Fan : 80 mm x 80 mm x 4 pcs
Fan Speed Mode :
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan : Yes
Power Recovery : Yes
Noise Level* : 50.2 dB(A)
Scheduled Power On / Off : Yes
Wake on LAN / WAN : Yes
Power Supply Unit / Adapter : 500 W
Redundant Power Supply : Yes
AC Input Power Voltage : 100 V to 240 V AC
Power Frequency : 50/60 Hz, Single Phase
Power Consumption* :
133.9 W (Access)
69.18 W (HDD Hibernation)
British Thermal Unit :
456.89 BTU/hr (Access)
236.05 BTU/hr (HDD Hibernation)
Temperature :
Operating Temperature : 5°C to 35°C (40°F to 95°F)
Storage Temperature : -20°C to 60°C (-5°F to 140°F)
Relative Humidity : 5% to 95% RH
Warranty : 5 Years
CPU :
CPU Model : Intel Xeon D-1527
CPU Architecture : 64-bit
CPU Frequency : Quad Core 2.2 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI) : Yes
Memory :
System Memory : 8GB DDR4 ECC UDIMM
Memory Module Pre-installed : 8 GB (8 GB x 1)
Total Memory Slots: 4
Memory Expandable up to : 64 GB (16 GB x 4)
Storage :
Drive Bays : 4
Maximum Drive Bays with Expansion Unit : 16
M.2 Drive Slots
2 (NVMe & SATA)
Compatible Drive Type* (See all supported drives) :
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
M.2 2280 NVMe & SATA SSD
Maximum Internal Raw Capacity : 64 TB (16 TB drive x 4) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units : 256 TB (64 TB + 16 TB drive x 12) (Capacity may vary by RAID types)
Maximum Single Volume Size* :
200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)
108 TB
Hot Swappable Drive : Yes
External Ports :
RJ-45 1GbE LAN Port : 4 (with Link Aggregation / Failover support)
USB 3.0 Port : 2
Expansion Port : 1
PCIe :
PCIe Expansion : 1 x Gen3 x8 slot (x8 link)
Add-In-Card Support : PCIe Network Interface Card (Learn more)
File System :
Internal Drives :
Btrfs
EXT4
External Drives :
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes : exFAT Access is purchased separately in Package Center.
Appearance :
Form Factor (RU) : 1U
Size (Height x Width x Depth) : 44 mm x 480 mm x 518.6 mm
Weight : 8.16 kg
Rack Installation Support* : 4-post 19" rack (Synology Rail Kit - RKM114/RKS1317)
Notes : The rail kit is sold separately
Others :
System Fan : 40 mm x 40 mm x 2 pcs
Fan Speed Mode :
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan : Yes
Power Recovery : Yes
Noise Level* : 39.3 dB(A)
Scheduled Power On / Off : Yes
Wake on LAN / WAN : Yes
Power Supply Unit / Adapter : 150 W
Redundant Power Supply : Yes
AC Input Power Voltage : 100 V to 240 V AC
Power Frequency: 50/60 Hz, Single Phase
Power Consumption* :
68.68 W (Access)
34.78 W (HDD Hibernation)
British Thermal Unit :
234.35 BTU/hr (Access)
118.67 BTU/hr (HDD Hibernation)
Temperature :
Operating Temperature : 5°C to 35°C (40°F to 95°F)
Storage Temperature : -20°C to 60°C (-5°F to 140°F)
Relative Humidity : 5% to 95% RH
Warranty : 5 Years
CPU :
CPU Model : Intel Xeon D-1521
CPU Architecture : 64-bit
CPU Frequency : Quad Core 2.4 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI) : Yes
Memory :
System Memory : 8 GB DDR4 ECC UDIMM
Memory Module Pre-installed : 8 GB (8 GB x 1)
Total Memory Slots : 4
Memory Expandable up to : 64 GB (16 GB x 4)
Storage :
Drive Bays : 12
Maximum Drive Bays with Expansion Unit : 36
Compatible Drive Type* (See all supported drives) :
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity : 192 TB (16 TB drive x 12) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units : 576 TB (192 TB + 16 TB drive x 24) (Capacity may vary by RAID types)
Maximum Single Volume Size* :
200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)
108 TB
Hot Swappable Drive : Yes
External Ports :
RJ-45 1GbE LAN Port : 4 (with Link Aggregation / Failover support)
USB 3.0 Port : 2
Expansion Port : 2
PCIe :
PCIe Expansion :2 x Gen3 x8 slots (x8 link)
Add-In-Card Support : PCIe Network Interface Card (Learn more)
M2D18 - Dual M.2 SATA SSD adapter card for SSD cache
Notes : RS3617RPxs with M2D18 can only support M.2 SATA SSD. M.2 NVMe/AHCI PCIe SSD is not supported.
File System :
Internal Drives :
Btrfs
EXT4
External Drives :
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes : exFAT Access is purchased separately in Package Center.
Appearance :
Form Factor (RU) : 2U
Size (Height x Width x Depth) : 88 mm x 482 mm x 724 mm
Weight : 14.5 kg
Rack Installation Support* : 4-post 19" rack (Synology Rail Kit - RKS1317)
Notes : The rail kit is sold separately
Others
System Fan : 80 mm x 80 mm x 4 pcs
Fan Speed Mode:
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan : Yes
Power Recovery : Yes
Noise Level* : 50.2 dB(A)
Scheduled Power On / Off : Yes
Wake on LAN / WAN : Yes
Power Supply Unit / Adapter : 500 W
Redundant Power Supply :Yes
AC Input Power Voltage : 100 V to 240 V AC
Power Frequency : 50/60 Hz, Single Phase
Power Consumption* :
116.42 W (Access)
65.49 W (HDD Hibernation)
British Thermal Unit :
397.24 BTU/hr (Access)
223.46 BTU/hr (HDD Hibernation)
Temperature :
Operating Temperature : 5°C to 35°C (40°F to 95°F)
Storage Temperature : -20°C to 60°C (-5°F to 140°F)
Relative Humidity : 5% to 95% RH
Warranty : 5 Years
CPU :
CPU Model : Intel Xeon D-1521
CPU Architecture : 64-bit
CPU Frequency : Quad Core 2.4 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI) : Yes
Memory :
System Memory : 8 GB DDR4 ECC UDIMM
Memory Module Pre-installed : 8 GB (8 GB x 1)
Total Memory Slots : 4
Memory Expandable up to : 64 GB (16 GB x 4)
Storage :
Drive Bays : 12
Maximum Drive Bays with Expansion Unit : 36
Compatible Drive Type* (See all supported drives) :
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity : 192 TB (16 TB drive x 12) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units : 576 TB (192 TB + 16 TB drive x 24) (Capacity may vary by RAID types)
Maximum Single Volume Size* : 200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only) 108 TB
Hot Swappable Drive :Yes
External Ports :
RJ-45 1GbE LAN Port : 4 (with Link Aggregation / Failover support)
USB 3.0 Port : 2
Expansion Port : 2
PCIe :
PCIe Expansion : 2 x Gen3 x8 slots (x8 link)
Add-In-Card Support : PCIe Network Interface Card (Learn more)
M2D18 - Dual M.2 SATA SSD adapter card for SSD cache
File System :
Internal Drives :
Btrfs
EXT4
External Drives:
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes : exFAT Access is purchased separately in Package Center.
Appearance :
Form Factor (RU): 2U
Size (Height x Width x Depth) : 88 mm x 482 mm x 724 mm
Weight: 14.5 kg
Rack Installation Support* : 4-post 19" rack (Synology Rail Kit - RKS1317)
Notes : The rail kit is sold separately
Others :
System Fan : 80 mm x 80 mm x 4 pcs
Fan Speed Mode :
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan : Yes
Power Recovery : Yes
Noise Level* : 50.2 dB(A)
Scheduled Power On / Off : Yes
Wake on LAN / WAN : Yes
Power Supply Unit / Adapter : 500 W
AC Input Power Voltage : 100 V to 240 V AC
Power Frequency : 50/60 Hz, Single Phase
Power Consumption* :
142.76 W (Access)
55.05 W (HDD Hibernation)
British Thermal Unit :
487.12 BTU/hr (Access)
187.84 BTU/hr (HDD Hibernation)
Temperature :
Operating Temperature : 5°C to 35°C (40°F to 95°F)
Storage Temperature : -20°C to 60°C (-5°F to 140°F)
Relative Humidity : 5% to 95% RH
Warranty : 5 Years
CPU :
CPU Model : Intel Xeon E3-1230 v2
CPU Architecture : 64-bit
CPU Frequency : Quad Core 3.3 (base) / 3.7 (turbo) GHz
Hardware Encryption Engine (AES-NI) : Yes
Memory :
System Memory : 8 GB DDR3 ECC
Memory Module Pre-installed : 8 GB (4 GB x 2)
Total Memory Slots : 4
Memory Expandable up to : 32 GB (8 GB x 4)
Storage :
Maximum Drive Bays with Expansion Unit : 180
Compatible Drive Type* (See all supported drives) :
3.5" SAS HDD
2.5" SAS HDD
2.5" SAS SSD
Maximum Raw Capacity with Expansion Units : 2,880 TB (16 TB drive x 180) (Capacity may vary by RAID types)
Maximum Single Volume Size* : 200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only) 108 TB
Hot Swappable Drive :Yes
-
External Ports :
RJ-45 1GbE LAN Port : 4 (with Link Aggregation / Failover support) + 1 for Heartbeat
USB 3.0 Port : 2
Expansion Port : 1
PCIe :
PCIe Expansion : 1 x Gen3 x8 slot (x8 link)
Add-In-Card Support : PCIe Network Interface Card (Learn more)
File System :
Internal Drives :
Btrfs
EXT4
External Drives :
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes : exFAT Access is purchased separately in Package Center.
Appearance :
Form Factor (RU) : 1U
Size (Height x Width x Depth) : 44 mm x 480 mm x 515 mm
Weight : 7.3 kg
Rack Installation Support* : 4-post 19" rack (Synology Rail Kit - RKM114/RKS1317)
Notes : The rail kit is sold separately
Others:
System Fan : 40 mm x 40 mm x 6 pcs
Fan Speed Mode :
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan : Yes
Power Recovery : Yes
Noise Level* :48 dB(A)
Scheduled Power On / Off : Yes
Wake on LAN / WAN : Yes
Power Supply Unit / Adapter : 150 W
Redundant Power Supply :Yes
AC Input Power Voltage : 100 V to 240 V AC
Power Frequency : 50/60 Hz, Single Phase
Power Consumption* : 60.16 W (Access)
British Thermal Unit :
205.27 BTU/hr (Access)
Temperature :
Operating Temperature : 5°C to 35°C (40°F to 95°F)
Storage Temperature : -20°C to 60°C (-5°F to 140°F)
Relative Humidity : 5% to 95% RH
Warranty : 5 Years
CPU :
CPU Model : Intel Xeon D-1527
CPU Architecture : 64-bit
CPU Frequency : Quad Core 2.2 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI) : Yes
Memory :
System Memory : 16 GB DDR4 ECC SO-DIMM
Memory Module Pre-installed : 16 GB (8 GB x 2)
Total Memory Slots : 4
Memory Expandable up to : 48 GB (16 GB + 16 GB x 2)
Storage :
Drive Bays : 12
Maximum Drive Bays with Expansion Unit : 36
Compatible Drive Type* (See all supported drives) :
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity : 192 TB (16 TB drive x 12) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units : 576 TB (192 TB + 16 TB drive x 24) (Capacity may vary by RAID types)
Maximum Single Volume Size* : 200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only) 108 TB
Hot Swappable Drive : Yes
External Ports :
RJ-45 1GbE LAN Port : 4 (with Link Aggregation / Failover support)
USB 3.0 Port : 2
Expansion Port : 2
PCIe :
PCIe Expansion : 1 x Gen3 x8 slot (x8 link)
Add-In-Card Support : PCIe Network Interface Card (Learn more)
M2D18 - Dual M.2 SATA SSD adapter card for SSD cache
Notes : DS3617xs with M2D18 can only support M.2 SATA SSD. M.2 NVMe/AHCI PCIe SSD is not supported.
File System :
Internal Drives :
Btrfs
EXT4
External Drives :
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes : exFAT Access is purchased separately in Package Center.
Appearance :
Size (Height x Width x Depth) : 270 mm x 300 mm x 340 mm
Weight : 9.8 kg
Others :
System Fan : 120 mm x 120 mm x 2 pcs
Fan Speed Mode :
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan : Yes
Power Recovery : Yes
Noise Level* : 22.3 dB(A)
Scheduled Power On / Off : Yes
Wake on LAN / WAN : Yes
Power Supply Unit / Adapter : 500 W
AC Input Power Voltage : 100 V to 240 V AC
Power Frequency : 50/60 Hz, Single Phase
Power Consumption* :
108.2 W (Access)
53.4 W (HDD Hibernation)
British Thermal Unit
369.4 BTU/hr (Access)
182.3 BTU/hr (HDD Hibernation)
Temperature :
Operating Temperature : 5°C to 40°C (40°F to 104°F)
Storage Temperature : -20°C to 60°C (-5°F to 140°F)
Relative Humidity: 5% to 95% RH
Warranty : 5 Years
CPU :
CPU Model : Intel Pentium D1508
CPU Architecture : 64-bit
CPU Frequency : Dual Core 2.2 (base) / 2.6 (turbo) GHz
Hardware Encryption Engine (AES-NI) : Yes
Memory :
System Memory : 8 GB DDR4 ECC SO-DIMM
Memory Module Pre-installed : 8 GB (8 GB x 1)
Total Memory Slots : 2
Memory Expandable up to : 32 GB (16 GB x 2)
Storage :
Drive Bays : 6
Maximum Drive Bays with Expansion Unit : 30
Compatible Drive Type* (See all supported drives) :
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity : 96 TB (16 TB drive x 6) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units : 480 TB (96 TB + 16 TB drive x 24) (Capacity may vary by RAID types)
Maximum Single Volume Size* : 200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only) 108 TB
Hot Swappable Drive : Yes
External Ports :
RJ-45 1GbE LAN Port : 4 (with Link Aggregation / Failover support)
USB 3.0 Port : 3
Expansion Port : 2
PCIe :
PCIe Expansion : 1 x Gen3 x8 slot (x8 link)
Add-In-Card Support : PCIe Network Interface Card (Learn more)
M2D18 - Dual M.2 SATA/NVMe SSD adapter card for SSD cache
File System :
Internal Drives :
Btrfs
EXT4
External Drives :
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes : exFAT Access is purchased separately in Package Center.
Appearance :
Size (Height x Width x Depth) : 166 mm x 282 mm x 243 mm
Weight : 5.2 kg
Others :
System Fan : 92 mm x 92 mm x 2 pcs
Fan Speed Mode :
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan : Yes
Brightness Adjustable Front LED Indicators : Yes
Power Recovery : Yes
Noise Level* : 25.5 dB(A)
Scheduled Power On / Off : Yes
Wake on LAN / WAN : Yes
Power Supply Unit / Adapter : 250 W
AC Input Power Voltage : 100 V to 240 V AC
Power Frequency : 50/60 Hz, Single Phase
Power Consumption* :
79.44 W (Access)
56.92 W (HDD Hibernation)
British Thermal Unit :
271.24 BTU/hr (Access)
194.35 BTU/hr (HDD Hibernation)
Temperature :
Operating Temperature : 5°C to 40°C (40°F to 104°F)
Storage Temperature : -20°C to 60°C (-5°F to 140°F)
Relative Humidity : 5% to 95% RH
Warranty : 5 Years
CPU
CPU Model Intel Celeron J3355CPU Architecture 64-bit
CPU Frequency Dual Core 2.0 (base) / 2.5 (burst) GHz
Hardware Encryption Engine (AES-NI)
Hardware Transcoding Engine H.264 (AVC), H.265 (HEVC), MPEG-2 and VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 30
Memory
System Memory 2 GB DDR3L
Memory Module Pre-installed 2 GB (2 GB x 1)
Total Memory Slots 2
Memory Expandable up to 6 GB (2 GB + 4 GB)
Notes
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
Drive Bays 6
Compatible Drive Type* (See all supported drives)
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity 46.08 TB (7.68 TB drive x 6) (Capacity may vary by RAID types)
Maximum Single Volume Size* 108 TB
Hot Swappable Drive Yes
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
Each internal volume (may consist of multiple drives) is expandable up to 108TB.
External Ports
RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support)
USB 3.0 Port 2
File System
Internal Drives : Btrfs / EXT4
External Drives : Btrfs / EXT4 / EXT3 / FAT / NTFS / HFS+ / exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 121 mm x 151 mm x 175 mm
Weight 1.4 kg
Others
System Fan 80 mm x 80 mm x 1 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 20.5 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 65 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 34.88 W (Access)
7.59 W (HDD Hibernation)
British Thermal Unit 119.1 BTU/hr (Access)
25.92 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10JFCX hard drive(s).
Noise Level Testing Environment: Fully loaded with WD 1TB WD10JFCX hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 17.2 dB(A); Temperature: 23.6?C; Humidity: 58.2%.
Temperature
Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification : EAC /VCCI/RCM/FCC/CE/BSMI/
Warranty : 2 Years
Notes
The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 2
Quick Installation Guide X 1
Optional Accessories
D3NS1866L-4G DDR3 non-ECC SO-DIMM
Surveillance Device License Pack
VS360HD
VS960HD
CPU
CPU Model Intel Celeron J3355
CPU Architecture 64-bit
CPU Frequency Dual Core 2.0 (base) / 2.5 (burst) GHz
Hardware Encryption Engine (AES-NI)
Hardware Transcoding Engine H.264 (AVC), H.265 (HEVC), MPEG-2 and VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 30
Memory
System Memory 2 GB DDR3L
Memory Module Pre-installed 2 GB (2 GB x 1)
Total Memory Slots 2
Memory Expandable up to 6 GB (2 GB + 4 GB)
Notes
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
Drive Bays 2
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity 32 TB (16 TB drive x 2) (Capacity may vary by RAID types)
Maximum Single Volume Size* 108 TB
Hot Swappable Drive Yes
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
Each internal volume (may consist of multiple drives) is expandable up to 108TB.
External Ports
RJ-45 1GbE LAN Port 1
USB 3.0 Port 3
eSATA Port 1
USB / SD Copy
File System
Internal Drives : Btrfs/EXT4
External Drives : Btrfs / EXT4 / EXT3/ FAT/ NTFS / HFS+ / exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 165 mm x 108 mm x 232.2 mm
Weight 1.30 kg
Others
System Fan 92 mm x 92 mm x 1 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mod
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 19.3 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 60 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 17.23 W (Access)
5.4 W (HDD Hibernation)
British Thermal Unit 58.79 BTU/hr (Access)
18.43 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification : EAC / VCCI / CCC / RCM / KC / FCC / CE / BSMI
Warranty : 2 Years
CPU
CPU Model Intel Celeron J3455
CPU Architecture 64-bit
CPU Frequency Quad Core 1.5 (base) / 2.3 (burst) GHz
Hardware Encryption Engine (AES-NI)
Hardware Transcoding Engine H.264 (AVC), H.265 (HEVC), MPEG-2 and VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 30
Memory
System Memory 2 GB DDR3L
Memory Module Pre-installed 2 GB (2 GB x 1)
Total Memory Slots 2
Memory Expandable up to 6 GB (2 GB + 4 GB)
Notes
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
Drive Bays 2
Maximum Drive Bays with Expansion Unit 7
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity 32 TB (16 TB drive x 2) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units 112 TB (32 TB + 16 TB drive x 5) (Capacity may vary by RAID types)
Maximum Single Volume Size* 108 TB
Hot Swappable Drive yes
Notes
Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit. (Learn more)
Each internal volume (may consist of multiple drives) is expandable up to 108TB.
External Ports
RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support)
USB 3.0 Port 3
eSATA Port 1
USB / SD Copy
File System
Internal Drives :
Btrfs
EXT4
External Drives
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 157 mm x 103.5 mm x 232 mm
Weight 1.74 kg
Others
System Fan 92 mm x 92 mm x 1 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 18.4 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 65 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 20.1 W (Access)
9.1 W (HDD Hibernation)
British Thermal Unit 68.58 BTU/hr (Access)
31.05 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification : EAC/ VCCI/ CCC/RCM/KC/FCC/CE/BSMI
Warranty : 3-year hardware warranty, extendable to 5-year coverage - EW201
Notes : The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 2
Quick Installation Guide X 1
Optional Accessories
D3NS1866L-4G DDR3 non-ECC SO-DIMM
Surveillance Device License Pack
Expansion Unit: DX517 X 1
VS360HD
VS960HD
CPU
CPU Model Intel Celeron J3455
CPU Architecture 64-bit
CPU Frequency Quad Core 1.5 (base) / 2.3 (burst) GHz
Hardware Encryption Engine (AES-NI)
Hardware Transcoding Engine H.264 (AVC), H.265 (HEVC), MPEG-2 and VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 30
Memory
System Memory 4 GB DDR3L
Memory Module Pre-installed 4 GB (4 GB x 1)
Total Memory Slots 2
Memory Expandable up to 8 GB (4 GB x 2)
Notes
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
Drive Bays 4
Maximum Drive Bays with Expansion Unit 9
M.2 Drive Slots 2 (NVMe)
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
M.2 2280 NVMe SSD
Maximum Internal Raw Capacity 64 TB (16 TB drive x 4) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units 144 TB (64 TB + 16 TB drive x 5) (Capacity may vary by RAID types)
Maximum Single Volume Size* 108 TB
Hot Swappable Drive yes
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit. (Learn more)
Each internal volume (may consist of multiple drives) is expandable up to 108TB.
External Ports
RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support)
USB 3.0 Port 2
eSATA Port 1
File System
Internal Drives
Btrfs
EXT4
External Drives
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 166 mm x 199 mm x 223 mm
Weight 2.28 kg
Others
System Fan 92 mm x 92 mm x 2 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 19.8 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 100 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 28.8 W (Access)
12.6 W (HDD Hibernation)
British Thermal Unit 98.27 BTU/hr (Access)
42.99 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
EAC
VCCI
CCC
RCM
KC
FCC
CE
BSMI
Warranty : 3-year hardware warranty, extendable to 5-year coverage - EW201
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment :
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 2
Quick Installation Guide X 1
Optional Accessories :
D3NS1866L-4G DDR3 non-ECC SO-DIMM
Surveillance Device License Pack
Expansion Unit: DX517 X 1
VS360HD
VS960HD
CPU
CPU Model Intel Celeron J3455
CPU Architecture 64-bit
CPU Frequency Quad Core 1.5 (base) / 2.3 (burst) GHz
Hardware Encryption Engine (AES-NI)
Hardware Transcoding Engine H.264 (AVC), H.265 (HEVC), MPEG-2 and VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 30
Memory
System Memory 8 GB DDR3L
Memory Module Pre-installed 8 GB (4 GB x 2)
Total Memory Slots 2
Notes
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
Drive Bays 5
Maximum Drive Bays with Expansion Unit 10
M.2 Drive Slots 2 (NVMe)
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
M.2 2280 NVMe SSD
Maximum Internal Raw Capacity 80 TB (16 TB drive x 5) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units 160 TB (80 TB + 16 TB drive x 5) (Capacity may vary by RAID types)
Maximum Single Volume Size* 108 TB
Hot Swappable Drive yes
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit. (Learn more)
Each internal volume (may consist of multiple drives) is expandable up to 108TB.
External Ports
RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support)
USB 3.0 Port 2
eSATA Port 1
File System
Internal Drives
Btrfs
EXT4
External Drives
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 166 mm x 230 mm x 223 mm
Weight 2.54 kg
Others
System Fan 92 mm x 92 mm x 2 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 20.8 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 120 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 38.59 W (Access)
13.32 W (HDD Hibernation)
British Thermal Unit 131.67 BTU/hr (Access)
45.45 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
EAC
VCCI
CCC
RCM
FCC
CE
BSMI
Warranty : 3-year hardware warranty, extendable to 5-year coverage - EW201
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 2
Quick Installation Guide X 1
Optional Accessories
Surveillance Device License Pack
Expansion Unit: DX517 X 1
VS360HD
VS960HD
CPU
CPU Model Intel Atom C3538
CPU Architecture 64-bit
CPU Frequency Quad Core 2.1 GHz
Hardware Encryption Engine (AES-NI)
Memory
System Memory 4 GB DDR4
Memory Module Pre-installed 4 GB (4 GB x 1)
Total Memory Slots 2
Memory Expandable up to 32 GB (16 GB x 2)
Notes
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
Drive Bays 6
Maximum Drive Bays with Expansion Unit 16
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity 96 TB (16 TB drive x 6) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units 256 TB (96 TB + 16 TB drive x 10) (Capacity may vary by RAID types)
Maximum Single Volume Size* 108 TB
Hot Swappable Drive yes
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit. (Learn more)
Each internal volume (may consist of multiple drives) is expandable up to 108TB.
External Ports
RJ-45 1GbE LAN Port 4 (with Link Aggregation / Failover support)
USB 3.0 Port 3
eSATA Port 2
PCIe
PCIe Expansion 1 x Gen3 x8 slot (black, x4 link)
Add-In-Card Support
PCIe Network Interface Card (Learn more)
M2D18 - Dual M.2 SATA/NVMe SSD adapter card for SSD cache
File System
Internal Drives
Btrfs
EXT4
External Drives
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+*
HFS+
exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 166 mm x 282 mm x 243 mm
Weight 5.05 kg
Others
System Fan 92 mm x 92 mm x 2 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 23.7 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 250 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 56.86 W (Access)
25.76 W (HDD Hibernation)
British Thermal Unit 194.01 BTU/hr (Access)
87.9 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
FCC
CE
EAC
BSMI
VCCI
CCC
RCM
KC
Warranty : 3-year hardware warranty, extendable to 5-year coverage - EW201
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Cord X 1
RJ-45 LAN Cable X 2
Quick Installation Guide X 1
Optional Accessories
D4NESO-2666-4G DDR4 non-ECC SO-DIMM*
D4ECSO-2666-16G DDR4 ECC SO-DIMM*
Surveillance Device License Pack
Expansion Unit: DX517 X 2
Synology Ethernet Adapter E10G17-F2
Synology Ethernet Adapter E10G18-T1
Synology Ethernet Adapter E10G18-T2
Synology M2D18 M.2 SSD adapter card
VS360HD
VS960HD
CPU
CPU Model Intel Atom C3538
CPU Architecture 64-bit
CPU Frequency Quad Core 2.1 GHz
Hardware Encryption Engine (AES-NI)
Memory
System Memory 4 GB DDR4
Memory Module Pre-installed 4 GB (4 GB x 1)
Total Memory Slots 2
Memory Expandable up to 32 GB (16 GB x 2)
Notes
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
Drive Bays 8
Maximum Drive Bays with Expansion Unit 18
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity 128 TB (16 TB drive x 8) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units 288 TB (128 TB + 16 TB drive x 10) (Capacity may vary by RAID types)
Maximum Single Volume Size* 108 TB
Hot Swappable Drive yes
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit. (Learn more)
Each internal volume (may consist of multiple drives) is expandable up to 108TB.
External Ports
RJ-45 1GbE LAN Port 4 (with Link Aggregation / Failover support)
USB 3.0 Port 4
eSATA Port 2
PCIe
PCIe Expansion 1 x Gen3 x8 slot (black, x4 link)
Add-In-Card Support
PCIe Network Interface Card (Learn more)
M2D18 - Dual M.2 SATA/NVMe SSD adapter card for SSD cache
File System
Internal Drives
Btrfs
EXT4
External Drives
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 166 mm x 343 mm x 243 mm
Weight 6 kg
Others
System Fan 120 mm x 120 mm x 2 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 22.2 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 250 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 66.96 W (Access)
29.39 W (HDD Hibernation)
British Thermal Unit 228.63 BTU/hr (Access)
100.35 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature :
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
FCC
CE
EAC
BSMI
VCCI
CCC
RCM
KC
Warranty : 3-year hardware warranty, extendable to 5-year coverage - EW201
Notes : The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Cord X 1
RJ-45 LAN Cable X 2
Quick Installation Guide X 1
Optional Accessories
D4NESO-2666-4G DDR4 non-ECC SO-DIMM*
D4ECSO-2666-16G DDR4 ECC SO-DIMM*
Surveillance Device License Pack
Expansion Unit: DX517 X 2
Synology Ethernet Adapter E10G17-F2
Synology Ethernet Adapter E10G18-T1
Synology Ethernet Adapter E10G18-T2
Synology M2D18 M.2 SSD adapter card
VS360HD
VS960HD
CPU
CPU Model Realtek RTD1296
CPU Architecture 64-bit
CPU Frequency Quad Core 1.4 GHz
Hardware Encryption Engine
Hardware Transcoding Engine 10-bit H.265 (HEVC), MPEG-4 Part 2, MPEG-2, VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 60
Memory
System Memory 1 GB DDR4
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays 2
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD (with optional 2.5" Disk Holder)
2.5" SATA SSD (with optional 2.5" Disk Holder)
Maximum Internal Raw Capacity 32 TB (16 TB drive x 2) (Capacity may vary by RAID types)
Maximum Single Volume Size* 108 TB
Hot Swappable Drive - yes
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
External Ports
RJ-45 1GbE LAN Port 1
USB 3.0 Port 2
File System
Internal Drives
EXT4
External Drives
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 165 mm x 100 mm x 225.5 mm
Weight 0.87 kg
Others
System Fan 92 mm x 92 mm x 1 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 19.9 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 60 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 16.79 W (Access)
5.16 W (HDD Hibernation)
British Thermal Unit 57.29 BTU/hr (Access)
17.61 BTU/hr (HDD Hibernation)
Notes Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
EAC
CCC
RCM
KC
FCC
CE
BSMI
Warranty : 2 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 1
Quick Installation Guide X 1
Optional Accessories
Surveillance Device License Pack
VS360HD
VS960HD
Disk Holder: Type C
CPU
CPU Model Intel Celeron J3355
CPU Architecture 64-bit
CPU Frequency Dual Core 2.0 (base) / 2.5 (burst) GHz
Hardware Encryption Engine (AES-NI)
Hardware Transcoding Engine H.264 (AVC), H.265 (HEVC), MPEG-2 and VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 30
Memory
System Memory 2 GB DDR3L
Memory Module Pre-installed 2 GB (2 GB x 1)
Total Memory Slots 2
Memory Expandable up to 6 GB (2 GB + 4 GB)
Notes
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
Drive Bays 4
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity 64 TB (16 TB drive x 4) (Capacity may vary by RAID types)
Maximum Single Volume Size* 108 TB
Hot Swappable Drive Yes
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
Each internal volume (may consist of multiple drives) is expandable up to 108TB.
External Ports
RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support)
USB 3.0 Port 2
File System
Internal Drives
Btrfs
EXT4
External Drives
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 166 mm x 199 mm x 223 mm
Weight 2.23 kg
Others
System Fan 92 mm x 92 mm x 2 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 20.5 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 90 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 29.01 W (Access)
10.59 W (HDD Hibernation)
British Thermal Unit 98.98 BTU/hr (Access)
36.12 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10JFCX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
EAC
CCC
RCM
KC
FCC
CE
BSMI
Warranty : 2 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 2
Quick Installation Guide X 1
Optional Accessories
D3NS1866L-4G DDR3 non-ECC SO-DIMM
Surveillance Device License Pack
VS360HD
VS960HD
CPU
CPU Model Realtek RTD1296
CPU Architecture 64-bit
CPU Frequency Quad Core 1.4 GHz
Hardware Encryption Engine
Hardware Transcoding Engine 10-bit H.265 (HEVC), MPEG-4 Part 2, MPEG-2, VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 60
Memory
System Memory 1 GB DDR4
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays 1
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD (with optional 2.5" Disk Holder)
2.5" SATA SSD (with optional 2.5" Disk Holder)
Maximum Internal Raw Capacity 16 TB (16 TB drive x 1) (Capacity may vary by RAID types)
Maximum Single Volume Size* 108 TB
Hot Swappable Drive - yes
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
External Ports
RJ-45 1GbE LAN Port 1
USB 3.0 Port 2
File System
Internal Drives
EXT4
External Drives
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 166 mm x 71 mm x 224 mm
Weight 0.7 kg
Others
System Fan 60 mm x 60 mm x 1 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Low-power Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 16.7 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 36 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 9.4 W (Access)
4.22 W (HDD Hibernation)
British Thermal Unit 32.1 BTU/hr (Access)
14.41 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
EAC
CCC
RCM
KC
FCC
CE
BSMI
Warranty : 2 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
RJ-45 LAN Cable X 1
Quick Installation Guide X 1
Optional Accessories
Surveillance Device License Pack
VS360HD
VS960HD
Disk Holder: Type C
CPU
CPU Model Realtek RTD1296
CPU Architecture 64-bit
CPU Frequency Quad Core 1.4 GHz
Hardware Encryption Engine
Hardware Transcoding Engine 10-bit H.265 (HEVC), MPEG-4 Part 2, MPEG-2, VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 60
Memory
System Memory 2 GB DDR4
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays 2
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity 32 TB (16 TB drive x 2) (Capacity may vary by RAID types)
Maximum Single Volume Size* 108 TB
Hot Swappable Drive Yes
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
External Ports
RJ-45 1GbE LAN Port 1
USB 2.0 Port 1
USB 3.0 Port 2
USB / SD Copy
File System
Internal Drives
Btrfs
EXT4
External Drives
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 165 mm x 108 mm x 233.2 mm
Weight 1.3 kg
Others
System Fan 92 mm x 92 mm x 1 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 19.3 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 60 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 14.99 W (Access)
5.78 W (HDD Hibernation)
British Thermal Unit 51.15 BTU/hr (Access)
19.72 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
EAC
CCC
RCM
KC
FCC
CE
BSMI
Warranty : 2 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 1
Quick Installation Guide X 1
Optional Accessories
Surveillance Device License Pack
VS360HD
VS960HD
CPU
CPU Model Realtek RTD1296
CPU Architecture 64-bit
CPU Frequency Quad Core 1.4 GHz
Hardware Encryption Engine
Hardware Transcoding Engine 10-bit H.265 (HEVC), MPEG-4 Part 2, MPEG-2, VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 60
Memory
System Memory 2 GB DDR4
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays 4
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity 64 TB (16 TB drive x 4) (Capacity may vary by RAID types)
Maximum Single Volume Size* 108 TB
Hot Swappable Drive
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
External Ports
RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support)
USB 3.0 Port 2
File System
Internal Drives
Btrfs
EXT4
External Drives
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 166 mm x 199 mm x 223 mm
Weight 2.28 kg
Others
System Fan 92 mm x 92 mm x 2 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 20.9 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 90 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 26.49 W (Access)
8.78 W (HDD Hibernation)
British Thermal Unit 90.39 BTU/hr (Access)
29.96 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
EAC
CCC
RCM
KC
FCC
CE
BSMI
Warranty : 2 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 2
Quick Installation Guide X 1
Optional Accessories
Surveillance Device License Pack
VS360HD
VS960HD
CPU
CPU Model Marvell Armada 3700 88F3720
CPU Architecture 64-bit
CPU Frequency Dual Core 800 MHz
Hardware Encryption Engine
Memory
System Memory 512 MB DDR3L
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays 1
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD (with optional 2.5" Disk Holder)
Maximum Internal Raw Capacity 16 TB (16 TB drive x 1) (Capacity may vary by RAID types)
Maximum Single Volume Size* 108 TB
Hot Swappable Drive -
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
External Ports
RJ-45 1GbE LAN Port 1
USB 2.0 Port 2
File System
Internal Drives
EXT4
External Drives
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 166 mm x 71 mm x 224 mm
Weight 0.7 kg
Others
System Fan 60 mm x 60 mm x 1 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Low-power Mode
Power Recovery
Noise Level* 16.9 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 36 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 9.81 W (Access)
4.68 W (HDD Hibernation)
British Thermal Unit 33.47 BTU/hr (Access)
15.97 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
FCC
CE
EAC
BSMI
VCCI
CCC
RCM
KC
Warranty : 2 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
RJ-45 LAN Cable X 1
Quick Installation Guide X 1
Optional Accessories
Surveillance Device License Pack
VS360HD
VS960HD
Disk Holder: Type C
CPU
CPU Model Marvell Armada 385 88F6820
CPU Architecture 32-bit
CPU Frequency Dual Core 1.3 GHz
Hardware Encryption Engine
Memory
System Memory 512 MB DDR3
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays 2
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD (with optional 2.5" Disk Holder)
2.5" SATA SSD (with optional 2.5" Disk Holder)
Maximum Internal Raw Capacity 32 TB (16 TB drive x 2) (Capacity may vary by RAID types)
Maximum Single Storage Pool Size 16 TB
Maximum Single Volume Size* 16 TB
Hot Swappable Drive - yes
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit. (Learn more)
External Ports
RJ-45 1GbE LAN Port 1
USB 3.0 Port 2
File System
Internal Drives
EXT4
External Drives
EXT4
EXT3
FAT
NTFS
HFS+*
exFAT*
Notes
HFS+ is read only, max 2TB volume size.
exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 165 mm x 100 mm x 225.5 mm
Weight 0.88 kg
Others
System Fan 92 mm x 92 mm x 1 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Low-power Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 18.2 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 60 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 17.48 W (Access)
7.03 W (HDD Hibernation)
British Thermal Unit 59.68 BTU/hr (Access)
24 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
EAC
CCC
RCM
KC
FCC
CE
BSMI
Warranty : 2 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 1
Quick Installation Guide X 1
Optional Accessories
Surveillance Device License Pack
VS360HD
VS960HD
Disk Holder: Type C
CPU
CPU Model Realtek RTD1296
CPU Architecture 64-bit
CPU Frequency Quad Core 1.4 GHz
Hardware Encryption Engine
Memory
System Memory 512 MB DDR4
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays 2
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD (with optional 2.5" Disk Holder)
2.5" SATA SSD (with optional 2.5" Disk Holder)
Maximum Internal Raw Capacity 32 TB (16 TB drive x 2) (Capacity may vary by RAID types)
Maximum Single Volume Size* 108 TB
Hot Swappable Drive -
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
External Ports
RJ-45 1GbE LAN Port 1
USB 3.0 Port 2
File System
Internal Drives
EXT4
External Drives
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 165 mm x 100 mm x 225.5 mm
Weight 0.88 kg
Others
System Fan 92 mm x 92 mm x 1 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Low-power Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 18.2 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 60 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 12.46 W (Access)
5.06 W (HDD Hibernation)
British Thermal Unit 45.52 BTU/hr (Access)
17.27 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
FCC
CE
EAC
BSMI
VCCI
CCC
RCM
KC
Warranty : 2 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 1
Quick Installation Guide X 1
Optional Accessories
Surveillance Device License Pack
VS360HD
VS960HD
Disk Holder: Type C
CPU
CPU Model Marvell Armada 385 88F6820
CPU Architecture 32-bit
CPU Frequency Dual Core 1.0 GHz
Hardware Encryption Engine
Memory
System Memory 512 MB DDR3
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays 4
Compatible Drive Type* (See all supported drives)
2.5" SATA HDD (up to 12.5 mm drive height)
2.5" SATA SSD
Maximum Internal Raw Capacity 30.72 TB (7.68 TB drive x 4) (Capacity may vary by RAID types)
Maximum Single Storage Pool Size 16 TB
Maximum Single Volume Size* 16 TB
Hot Swappable Drive yes
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
External Ports
RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support)
USB 3.0 Port 2
File System
Internal Drives
EXT4
External Drives
EXT4
EXT3
FAT
NTFS
HFS+*
exFAT*
Notes
HFS+ is read only, max 2TB volume size.
exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 120 mm x 105 mm x 142 mm
Weight 0.66 kg
Others
System Fan 60 mm x 60 mm x 1 pcs
Fan Speed Mode
Cool Mode
Quiet Mode
Low-power Mode
Easy Replacement System Fan
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 20.3 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 30 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 17.17 W (Access)
11.63 W (HDD Hibernation)
British Thermal Unit 58.63 BTU/hr (Access)
39.71 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10JFCX hard drive(s).
Noise Level Testing Environment: Fully loaded with WD 1TB WD10JFCX hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 17.2 dB(A); Temperature: 23.6?C; Humidity: 58.2%.
Temperature
Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
EAC
CCC
RCM
KC
FCC
CE
BSMI
Warranty :2 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Welcome Note X 1
Accessory Pack X 1
AC Power Adapter X 1
RJ-45 LAN Cable X 2
Optional Accessories
Surveillance Device License Pack
VS360HD
VS960HD
CPU
CPU Model Marvell Armada 385 88F6820
CPU Architecture 32-bit
CPU Frequency Dual Core 1.33 GHz
Hardware Encryption Engine
Memory
System Memory 512 MB DDR3L
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays 4
Compatible Drive Type* (See all supported drives)
2.5" SATA HDD (up to 12.5 mm drive height)
2.5" SATA SSD
Maximum Internal Raw Capacity 30.72 TB (7.68 TB drive x 4) (Capacity may vary by RAID types)
Maximum Single Storage Pool Size 16 TB
Maximum Single Volume Size* 16 TB
Hot Swappable Drive Yes
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
External Ports
RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support)
USB 3.0 Port 2
File System
Internal Drives
EXT4
External Drives
EXT4
EXT3
FAT
NTFS
HFS+*
exFAT*
Notes
HFS+ is read only, max 2TB volume size.
exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 120 mm x 105 mm x 142 mm
Weight 0.66 kg
Others
System Fan 60 mm x 60 mm x 1 pcs
Fan Speed Mode
Cool Mode
Quiet Mode
Low-power Mode
Easy Replacement System Fan
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 20.3 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 30 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 20.28 W (Access)
7.27 W (HDD Hibernation)
British Thermal Unit 69.24 BTU/hr (Access)
24.82 BTU/hr (HDD Hibernation)
Notes
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10JFCX hard drive(s).
Noise Level Testing Environment: Fully loaded with WD 1TB WD10JFCX hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 17.2 dB(A); Temperature: 23.6?C; Humidity: 58.2%.
Temperature
Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
EAC
VCCI
CCC
RCM
KC
FCC
CE
BSMI
Warranty : 2 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
AC Power Adapter X 1
RJ-45 LAN Cable X 2
Quick Installation Guide X 1
Optional Accessories
Surveillance Device License Pack
VS360HD
VS960HD
Hardware Specifications
Applied Models
Supports creating volumes across different units
DS1819+
DS1817+
DS1817
DS1815+
DS1618+
DS1517+
DS1517
DS1515+
DS1515
DS1019+
DS918+
DS916+
DS718+
DS716+
DS716+II
DVA3219
NVR1218
Supports creating volumes on a single unit only
DS415+
DS218+
DS216+
DS216+II
NVR216
Notes
For more information on the compatibility of each expansion unit, please refer to this article.
Please upgrade to DSM 6.2.1-23824-5 or later version before using it with 15 and 16 series models (excluding DS1515, DS716+, and DS716+II).
To have better performance, we recommend creating storage volumes physically located within the same NAS or Expansion Unit, rather than creating volumes across your NAS and Expansion Unit.
Storage
Drive Bays 5
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity 80 TB (16 TB drive x 5) (Capacity may vary by RAID types)
Hot Swappable Drive Yes
RAID Management through Synology DSM
External Ports
eSATA Port 1
Appearance
Size (Height x Width x Depth) 157 mm x 248 mm x 233 mm
Weight 3.91 kg
Power
Power Recovery Synchronized with the Synology DiskStation
Power Supply Unit / Adapter 200 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 29.9 W (Access)
2.4 W (HDD Hibernation)
British Thermal Unit 102.02 BTU/hr (Access)
8.19 BTU/hr (HDD Hibernation)
Notes Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Temperature
Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -10°C to 70°C (15°F to 155°F)
Relative Humidity 5% to 95% RH
Others
System Fan 80 mm x 80 mm x 2 pcs
Easy Replacement System Fan
Noise Level* 21.5 dB(A)
Notes Noise Level Testing Environment: Fully loaded with Seagate 1TB ST31000520AS hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%
Certification
FCC
CE
BSMI
Warranty : 3-year hardware warranty, extendable to 5-year coverage - EW201
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment & Packaging
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Cord X 1
Expansion Cable: eSATA X 1
Quick Installation Guide X 1
Click To Call
