TR3BF Series
Brightness(w/Protection Glass) : 330 cd/m²
Touch Type : IR
Multi Touch Point : Max 20 points / Max 10 writing
Interface : HDMI (3), RGB / Audio In,RS232C In, RJ45,USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update),
USB 3.0 (3), Touch Out(USB2.0,B Type) (2),HDMI (1), Optical Output / Audio Out
PANEL
Screen Size 86 Panel Technology IPS
Back Light Type Direct Aspect Ratio 16 : 9
Native Resolution 3,840 x 2,160 (UHD) Brightness(Typ., cd/m², w/ Protection Glass) 330
Contrast Ratio 1,100:1 Viewing Angle(H x V) 178 x 178
Response Time 8 ms (G to G) Life Time (Typ.) 30,000 Hrs (Min.)
Operation Hours 16Hr Orientation Landscape
CONNECTIVITY
(Input) Video / Audio HDMI (3), RGB / Audio In (Input) External Control RS232C In, RJ45
(Input) USB USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update), USB 3.0 (3), Touch Out(USB2.0,B Type) (2) (Output) Video / Audio HDMI (1), Optical Output / Audio Out
MECHANICAL SPECIFICATION
Bezel Color Black Bezel Width(Off Bezel) Top/Right/Left:17.7mm, Bottom:45.7mm
Monitor Dimension (W × H × D) 1,957×1,160×86mm Weight (Head) 67kg
Carton Dimensions(W x H x D) with pallet 2,230×1,499×285mm Packed Weight 109kg
Handle Yes VESA™ Standard Mount Interface 800 x 600
ENVIRONMENT CONDITIONS
Operation Temperature 0 °C to 40 °C Operation Humidity 10 % to 80 %
POWER
Power Supply 100 -240V~, 50/60Hz Power Type Built-In Power
Power Consumption (Typ. / Max.) 365W / 419W
SOUND
Speaker Built in 24W (12W + 12W)
STANDARD(CERTIFICATION)
Safety CB / NRTL EMC FCC Class "A" / CE
ErP / Energy Star Yes(EU Only) / No
MEDIA PLAYER COMPATIBILITY
OPS Type Compatible Yes
ACCESSORY
Basic Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Control
SPECIAL FEATURE
Embedded Writing Software Yes
TOUCH SPECIFICATIONS
Touch Type IR Available Object Size for Touch Ø3 mm ?
Response Time 60ms ? (Android) / 100ms ? (Windows) Accuracy 1.5mm
Interface USB 2.0 Protection Glass Thickness 4T (Anti-Glare)
Protection Glass Transmission 87% Operating System Support Windows 7/8/10/WindowsXP/Linux/Mac/Android (WindowsXP/Linux/Mac Support one point touch)
Multi touch point Max 20 points / Max 10 writing
TR3BF Series
Brightness(w/Protection Glass) : 330 cd/m²
Touch Type : IR
Multi Touch Point : Max 20 points / Max 10 writing
Interface : HDMI (3), RGB / Audio In,RS232C In, RJ45,USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update),
USB 3.0 (3), Touch Out(USB2.0,B Type) (2),HDMI (1), Optical Output / Audio Out
PANEL
Screen Size 75 Panel Technology IPS
Back Light Type Direct Aspect Ratio 16 : 9
Native Resolution 3,840 x 2,160 (UHD) Brightness(Typ., cd/m², w/ Protection Glass) 330
Contrast Ratio 1,100:1 Viewing Angle(H x V) 178 x 178
Response Time 8 ms (G to G) Life Time (Typ.) 30,000 Hrs (Min.)
Operation Hours 16Hr Orientation Landscape
CONNECTIVITY
(Input) Video / Audio HDMI (3), RGB / Audio In (Input) External Control RS232C In, RJ45
(Input) USB USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update), USB 3.0 (3), Touch Out(USB2.0,B Type) (2) (Output) Video / Audio HDMI (1), Optical Output / Audio Out
MECHANICAL SPECIFICATION
Bezel Color Black Bezel Width(Off Bezel) Top/Right/Left:17.7mm, Bottom:45.7mm
Monitor Dimension (W × H × D) 1,957×1,160×86mm Weight (Head) 67kg
Carton Dimensions(W x H x D) with pallet 2,230×1,499×285mm Packed Weight 109kg
Handle Yes VESA™ Standard Mount Interface 800 x 600
ENVIRONMENT CONDITIONS
Operation Temperature 0 °C to 40 °C Operation Humidity 10 % to 80 %
POWER
Power Supply 100 -240V~, 50/60Hz Power Type Built-In Power
Power Consumption (Typ. / Max.) 365W / 419W
SOUND
Speaker Built in 24W (12W + 12W)
STANDARD(CERTIFICATION)
Safety CB / NRTL EMC FCC Class "A" / CE
ErP / Energy Star Yes(EU Only) / No
MEDIA PLAYER COMPATIBILITY
OPS Type Compatible Yes
ACCESSORY
Basic Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Control
SPECIAL FEATURE
Embedded Writing Software Yes
TOUCH SPECIFICATIONS
Touch Type IR Available Object Size for Touch Ø3 mm ?
Response Time 60ms ? (Android) / 100ms ? (Windows) Accuracy 1.5mm
Interface USB 2.0 Protection Glass Thickness 4T (Anti-Glare)
Protection Glass Transmission 87% Operating System Support Windows 7/8/10/WindowsXP/Linux/Mac/Android (WindowsXP/Linux/Mac Support one point touch)
Multi touch point Max 20 points / Max 10 writing
TR3BF Series
Brightness(w/Protection Glass) : 330 cd/m²
Touch Type : IR
Multi Touch Point : Max 20 points / Max 10 writing
Interface : HDMI (3), RGB / Audio In,RS232C In, RJ45,USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update),
USB 3.0 (3), Touch Out(USB2.0,B Type) (2),HDMI (1), Optical Output / Audio Out
PANEL
Screen Size 65 Panel Technology IPS
Back Light Type Direct Aspect Ratio 16 : 9
Native Resolution 3,840 x 2,160 (UHD) Brightness(Typ., cd/m², w/ Protection Glass) 330
Contrast Ratio 1,100:1 Viewing Angle(H x V) 178 x 178
Response Time 8 ms (G to G) Life Time (Typ.) 30,000 Hrs (Min.)
Operation Hours 16Hr Orientation Landscape
CONNECTIVITY
(Input) Video / Audio HDMI (3), RGB / Audio In (Input) External Control RS232C In, RJ45
(Input) USB USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update), USB 3.0 (3), Touch Out(USB2.0,B Type) (2) (Output) Video / Audio HDMI (1), Optical Output / Audio Out
MECHANICAL SPECIFICATION
Bezel Color Black Bezel Width(Off Bezel) Top/Right/Left:17.7mm, Bottom:45.7mm
Monitor Dimension (W × H × D) 1,957×1,160×86mm Weight (Head) 67kg
Carton Dimensions(W x H x D) with pallet 2,230×1,499×285mm Packed Weight 109kg
Handle Yes VESA™ Standard Mount Interface 800 x 600
ENVIRONMENT CONDITIONS
Operation Temperature 0 °C to 40 °C Operation Humidity 10 % to 80 %
POWER
Power Supply 100 -240V~, 50/60Hz Power Type Built-In Power
Power Consumption (Typ. / Max.) 365W / 419W
SOUND
Speaker Built in 24W (12W + 12W)
STANDARD(CERTIFICATION)
Safety CB / NRTL EMC FCC Class "A" / CE
ErP / Energy Star Yes(EU Only) / No
MEDIA PLAYER COMPATIBILITY
OPS Type Compatible Yes
ACCESSORY
Basic Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Control
SPECIAL FEATURE
Embedded Writing Software Yes
TOUCH SPECIFICATIONS
Touch Type IR Available Object Size for Touch Ø3 mm ?
Response Time 60ms ? (Android) / 100ms ? (Windows) Accuracy 1.5mm
Interface USB 2.0 Protection Glass Thickness 4T (Anti-Glare)
Protection Glass Transmission 87% Operating System Support Windows 7/8/10/WindowsXP/Linux/Mac/Android (WindowsXP/Linux/Mac Support one point touch)
Multi touch point Max 20 points / Max 10 writing
Brightness(Typ.) : 350 cd/m²
Touch Type : In-Cell
Multi Touch Point : Active Pen : Max 2 Point
Depth : 86.5 mm
Interface : HDMI (2), DP, DVI-D, USB Type C / Audio-in,RS232C In/Out,USB 2.0 (2), USB Type C(USB2.0), Touch Out(USB2.0,B Type)(2)
PANEL
Screen Size 218.44cm (86) Panel Technology IPS
Back Light Type Edge Aspect Ratio 16 : 9
Native Resolution 3,840 x 2,160 (UHD) Brightness(Typ., cd/m², w/ Protection Glass) 350
Contrast Ratio 1,000:1(TBD) Viewing Angle (H x V) 178 x 178
Response Time 8 ms(G to G) Life Time (Typ.) 30,000 Hrs (Min.)
Operation Hours 16Hr Orientation Landscape
CONNECTIVITY
Video / Audio HDMI (2), DP, DVI-D, USB External Control RS232C In/Out
USB USB 2.0 (2), USB Type C(USB2.0), Touch Out(USB2.0,B Type)(2)
MECHANICAL SPECIFICATION
Bezel Color Black Bezel Width (T/L/R/B) set: 28.8mm
Monitor Dimension (W × H × D) 1952.6 x 1164.1 x 86.4 mm Weight (Head) 66.7 kg
Carton Dimensions (W × H × D) 2190 x 1470 x 371 mm Packed Weight 95kg
Handle Yes VESA™ Standard Mount Interface 600 x 400
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10 % to 80 %
POWER
Power Supply 100-240V~, 50/60Hz Power Type Built-In Power
Power Consumption (Typ. / Max.) 360W / 420W
SOUND
Speaker Built in(10W/Ch)
STANDARD(CERTIFICATION)
Safety CB / NRTL EMC FCC Class "A" / CE / KC
MEDIA PLAYER COMPATIBILITY
OPS Type Compatible Yes Optional (OPS Kit (KT-OPSF))
ACCESSORY
Basic Remote Controller(include battery 2ea), Power Cord, QSG, HDMI(3M), Regulation Book, Phone to RS232C Gender, Touch Pen(2ea, include battery 2ea), Pen Tip(10ea), Tip Remover(2ea), USB Type-C Cable, Ferrite Core Filter
SPECIAL FEATURE
IDB App Yes
TOUCH SPECIFICATIONS
Touch Type In-cell Available Object Size for Touch Ø5 mm ?
Response Time (PC Windows 10) 70ms? Accuracy 1.5mm
Interface USB 2.0 Protection Glass Thickness 1.85T (Anti-Glare)
Protection Glass Transmission 88% Operating Systme Support Win7 professional, Win8.1, Win10
Multi touch point Finger : Max 20 Point (Windows), Finger: Max 10Point (webOS), Active Pen : Max 2 Point
Floating Tool Bar
SoC and LG webOS
IDB App for Efficient Collaboration
LG FHD Technology
LG IPS Panel with Wide Viewing Angles and True Color
Auto Signal/Touch Switching
PANEL
Screen Size 139.7cm (55) Panel Technology IPS
Aspect Ratio 16 : 9 Native Resolution 1,920 x 1,080 (FHD)
Brightness (cd/m²) 450 Viewing Angle (HxV) 178 x 178
Response Time 12ms (G to G BW), 9.0ms (WOT) Surface Treatment Hard coating (3H), Anti-glare treatment of the front polarizer, (Haze 1%(Typ.))
Life Time (Typ.) 50,000Hrs Operation Hours 24Hrs
Orientation Landscape & Portrait
CONNECTIVITY
Input HDMI (2), DP, DVI-D, RGB, Audio In, USB 3.0 Output DP, Audio Out
External Control RS232C In/out, RJ45 In, IR Receiver In, Pixer Sensor In
PHYSICAL SPECIFICATION
Bezel Color Black Bezel Width 32.7 mm (Even)
Monitor Dimension (W x H x D) 1,278 x 748.8 x 71.4 mm Weight (Head) 28.0 kg
Carton Dimensions (W x H x D) 1,410 x 880 x 207 mm Packed Weight 33kg
VESA™ Standard Mount Interface 300 x 300 mm
SPECIAL FEATURES
Yes Temperature Sensor, Auto Brightness Sensor, Tile Mode (Up to 15x15), Natural Mode @Tile Mode, ISM Method, DPM Select, Energy Saving,
Smart Energy Saving, File Play with USB, PIP/PBP (2), Internal Memory 8GB (System 4GB + Available 4GB), Wi-Fi Built-in (802.11n combo), USB Cloning,
Easy Brightness Control, IDB App. (Whiteboard App.), Fail Over, Mirroring, SoftAP, Beacon, Embedded Template, Built-in Speaker (10W+10W), Crestron Connected**
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10% to 80%
POWER
Power Type Built-in Power Power Supply 100 -240V~, 50/60Hz
Power Consumption Typ./Max. 100W/115W Power Consumption Smart Energy Saving 70W
STANDARD(CERTIFICATION)
Safety UL/cUL/CB/TUV/KC EMC FCC Class "A"/CE/KCC
MEDIA PLAYER COMPATIBILITY
OPS type compatible Yes External Media player Attatchable Yes (MP500/MP700)
SOFTWARE COMPATIBILITY
Content Management Software SuperSign CMS Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (2ea batteries included), Power cord, QSG, RGB cable, Regulation book, Phone to RS232C gender, Memory cover Optional
Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSA), HDBaseT (EB-B100)
TOUCH
Touch type IR (Scattering) Scan Time 10 ms ?
Interface USB 2.0 Protection Glass Thickness 2.8T (Anti-Glare)
Operating Systme Support Windows 7, Windows 8/8.1/10, Mac OS X (10.7 or later), Android, Linux (kernel 3.9 or later) Multi touch point Max 10 Points
Floating Tool Bar
SoC and LG webOS
IDB App for Efficient Collaboration
LG FHD Technology
LG IPS Panel with Wide Viewing Angles and True Color
Auto Signal/Touch Switching
PANEL
Screen Size 124.46cm (49) Panel Technology IPS
Aspect Ratio 16 : 9 Native Resolution 1,920 x 1,080 (FHD)
Brightness (cd/m²) 450 Viewing Angle (HxV) 178 x 178
Response Time 12ms (G to G BW), 9.0ms (WOT) Surface Treatment Hard coating (3H), Anti-glare treatment of the front polarizer, (Haze 1%(Typ.))
Life Time (Typ.) 50,000Hrs Operation Hours 24Hrs
Orientation Landscape & Portrait
CONNECTIVITY
Input HDMI (2), DP, DVI-D, RGB, Audio In, USB 3.0 Output DP, Audio Out
External Control RS232C In/out, RJ45 In, IR Receiver In, Pixer Sensor In
PHYSICAL SPECIFICATION
Bezel Color Black Bezel Width 32.7 mm (Even)
Monitor Dimension (W x H x D) 1,278 x 748.8 x 71.4 mm Weight (Head) 28.0 kg
Carton Dimensions (W x H x D) 1,410 x 880 x 207 mm Packed Weight 33kg
VESA Standard Mount Interface 300 x 300 mm
SPECIAL FEATURES
Yes Temperature Sensor, Auto Brightness Sensor, Tile Mode (Up to 15x15), Natural Mode @Tile Mode, ISM Method, DPM Select, Energy Saving,
Smart Energy Saving, File Play with USB, PIP/PBP (2), Internal Memory 8GB (System 4GB + Available 4GB), Wi-Fi Built-in (802.11n combo), USB Cloning,
Easy Brightness Control, IDB App. (Whiteboard App.), Fail Over, Mirroring, SoftAP, Beacon, Embedded Template, Built-in Speaker (10W+10W), Crestron Connected**
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10% to 80%
POWER
Power Type Built-in Power Power Supply 100 -240V~, 50/60Hz
Power Consumption Typ./Max. 100W/115W Power Consumption Smart Energy Saving 70W
STANDARD(CERTIFICATION)
Safety UL/cUL/CB/TUV/KC EMC FCC Class "A"/CE/KCC
MEDIA PLAYER COMPATIBILITY
OPS type compatible Yes External Media player Attatchable Yes (MP500/MP700)
SOFTWARE COMPATIBILITY
Content Management Software SuperSign CMS Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (2ea batteries included), Power cord, QSG, RGB cable, Regulation book, Phone to RS232C gender, Memory cover Optional
Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSA), HDBaseT (EB-B100)
TOUCH
Touch type IR (Scattering) Scan Time 10 ms ?
Interface USB 2.0 Protection Glass Thickness 2.8T (Anti-Glare)
Operating Systme Support Windows 7, Windows 8/8.1/10, Mac OS X (10.7 or later), Android, Linux (kernel 3.9 or later) Multi touch point Max 10 Points
Floating Tool Bar
SoC and LG webOS
IDB App for Efficient Collaboration
LG FHD Technology
LG IPS Panel with Wide Viewing Angles and True Color
Auto Signal/Touch Switching
PANEL
Screen Size 109.22cm (43) Panel Technology IPS
Aspect Ratio 16 : 9 Native Resolution 1,920 x 1,080 (FHD)
Brightness (cd/m²) 450 Viewing Angle (HxV) 178 x 178
Response Time 12ms (G to G BW), 9.0ms (WOT) Surface Treatment Hard coating (3H), Anti-glare treatment of the front polarizer, (Haze 1%(Typ.))
Life Time (Typ.) 50,000Hrs Operation Hours 24Hrs
Orientation Landscape & Portrait
CONNECTIVITY
Input HDMI (2), DP, DVI-D, RGB, Audio In, USB 3.0 Output DP, Audio Out
External Control RS232C In/out, RJ45 In, IR Receiver In, Pixer Sensor In
PHYSICAL SPECIFICATION
Bezel Color Black Bezel Width 32.7 mm (Even)
Monitor Dimension (W x H x D) 1,278 x 748.8 x 71.4 mm Weight (Head) 28.0 kg
Carton Dimensions (W x H x D) 1,410 x 880 x 207 mm Packed Weight 33kg
VESA™ Standard Mount Interface 300 x 300 mm
SPECIAL FEATURES
Yes Temperature Sensor, Auto Brightness Sensor, Tile Mode (Up to 15x15), Natural Mode @Tile Mode, ISM Method, DPM Select, Energy Saving,
Smart Energy Saving, File Play with USB, PIP/PBP (2), Internal Memory 8GB (System 4GB + Available 4GB), Wi-Fi Built-in (802.11n combo), USB Cloning,
Easy Brightness Control, IDB App. (Whiteboard App.), Fail Over, Mirroring, SoftAP, Beacon, Embedded Template, Built-in Speaker (10W+10W), Crestron Connected**
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10% to 80%
POWER
Power Type Built-in Power Power Supply 100 -240V~, 50/60Hz
Power Consumption Typ./Max. 100W/115W Power Consumption Smart Energy Saving 70W
STANDARD(CERTIFICATION)
Safety UL/cUL/CB/TUV/KC EMC FCC Class "A"/CE/KCC
MEDIA PLAYER COMPATIBILITY
OPS type compatible Yes External Media player Attatchable Yes (MP500/MP700)
SOFTWARE COMPATIBILITY
Content Management Software SuperSign CMS Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (2ea batteries included), Power cord, QSG, RGB cable, Regulation book, Phone to RS232C gender, Memory cover Optional
Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSA), HDBaseT (EB-B100)
TOUCH
Touch type IR (Scattering) Scan Time 10 ms ?
Interface USB 2.0 Protection Glass Thickness 2.8T (Anti-Glare)
Operating Systme Support Windows 7, Windows 8/8.1/10, Mac OS X (10.7 or later), Android, Linux (kernel 3.9 or later) Multi touch point Max 10 Points
Floating Tool Bar
SoC and LG webOS
IDB App for Efficient Collaboration
LG FHD Technology
LG IPS Panel with Wide Viewing Angles and True Color
Auto Signal/Touch Switching
PANEL
Screen Size 81.28Cm (32) Panel Technology IPS
Aspect Ratio 16 : 9 Native Resolution 1,920 x 1,080 (FHD)
Brightness (cd/m²) 450 Viewing Angle (HxV) 178 x 178
Response Time 12ms (G to G BW), 9.0ms (WOT) Surface Treatment Hard coating (3H), Anti-glare treatment of the front polarizer, (Haze 1%(Typ.))
Life Time (Typ.) 50,000Hrs Operation Hours 24Hrs
Orientation Landscape & Portrait
CONNECTIVITY
Input HDMI (2), DP, DVI-D, RGB, Audio In, USB 3.0 Output DP, Audio Out
External Control RS232C In/out, RJ45 In, IR Receiver In, Pixer Sensor In
PHYSICAL SPECIFICATION
Bezel Color Black Bezel Width 32.7 mm (Even)
Monitor Dimension (W x H x D) 1,278 x 748.8 x 71.4 mm Weight (Head) 28.0 kg
Carton Dimensions (W x H x D) 1,410 x 880 x 207 mm Packed Weight 33kg
VESA™ Standard Mount Interface 300 x 300 mm
SPECIAL FEATURES
Yes Temperature Sensor, Auto Brightness Sensor, Tile Mode (Up to 15x15), Natural Mode @Tile Mode, ISM Method, DPM Select, Energy Saving,
Smart Energy Saving, File Play with USB, PIP/PBP (2), Internal Memory 8GB (System 4GB + Available 4GB), Wi-Fi Built-in (802.11n combo), USB Cloning,
Easy Brightness Control, IDB App. (Whiteboard App.), Fail Over, Mirroring, SoftAP, Beacon, Embedded Template, Built-in Speaker (10W+10W), Crestron Connected**
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10% to 80%
POWER
Power Type Built-in Power Power Supply 100 -240V~, 50/60Hz
Power Consumption Typ./Max. 100W/115W Power Consumption Smart Energy Saving 70W
STANDARD(CERTIFICATION)
Safety UL/cUL/CB/TUV/KC EMC FCC Class "A"/CE/KCC
MEDIA PLAYER COMPATIBILITY
OPS type compatible Yes External Media player Attatchable Yes (MP500/MP700)
SOFTWARE COMPATIBILITY
Content Management Software SuperSign CMS Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (2ea batteries included), Power cord, QSG, RGB cable, Regulation book, Phone to RS232C gender, Memory cover Optional
Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSA), HDBaseT (EB-B100)
TOUCH
Touch type IR (Scattering) Scan Time 10 ms ?
Interface USB 2.0 Protection Glass Thickness 2.8T (Anti-Glare)
Operating Systme Support Windows 7, Windows 8/8.1/10, Mac OS X (10.7 or later), Android, Linux (kernel 3.9 or later) Multi touch point Max 10 Points
Brightness(Typ.): 410 cd/m²
Touch Type: InGlass™
Multi touch point: Max 20 Point
Interface: HDMI (3), DP, DVI, RGB, RS232C, RJ45, USB (2), OPS USB, Touch USB (2), Wi-fi Built-in
PANEL
Screen Size 218.44cm (86) Brightness(Module, Typ., cd/m²) 410
Native Resolution 3840 x 2160 (UHD)
CONNECTIVITY
Input HDMI (3), DP, DVI-D, RGB, Audio, USB 3.0, USB 2.0, OPS USB 2.0 Output Touch USB 2.0 (2)
PHYSICAL SPECIFICATION
Bezel Width 50.7 mm (T/L/R), 62.2 mm (B) Monitor Dimension (W x H x D) 2,026.9 x 1,180.3 x 92.9 mm
Weight (Head) 85.8 kg Carton Dimensions (W x H x D) 2,190 × 1,470 × 371 mm
Packed Weight 114.6 kg VESA™ Standard Mount Interface 600 x 400 mm
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10 % to 80 %
SOFTWARE COMPATIBILITY
Content Management Software SuperSign Premium Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (include battery 2ea), Power Cord, QSG, HDMI (3M), Regulation Book, Phone to RS232C Gender, Touch Pen (2ea), Eyebolt (2ea) Optional
OPS Kit (KT-OPSA)
TOUCH
Touch type InGlass™ Available object size for touch more than Ø 3 mm
Accuracy 2 mm Interface USB 2.0
Protection Glass Thickness 4T (Anti-Glare) Multi touch point Max 20 Point
Brightness: 500 cd/?
Touch Type: P-Cap(Ag Metal Mesh)
Touch Point: Max. 40 points
Interface: HDMI (3), DP, DVI, RGB, RS232C, RJ45, USB (2), OPS USB, Touch USB (2), Wi-Fi Built-in
PANEL
Screen Size 75” Native Resolution 3,840 x 2,160 (UHD)
Brightness (Module, cd/?) 500
CONNECTIVITY
Input HDMI (3), DP, DVI-D, RGB, Audio in, USB 3.0, USB 2.0, OPS USB 2.0 Output Touch USB 2.0 (2)
External Control RS232C in/out, RJ45 in
PHYSICAL SPECIFICATION
Bezel Width 41.6 mm(T/L/R/B) Monitor Dimension (W x H x D) 1,732.8 x 1011.1 x 69.7 mm (w/o Handle)
Weight (Head) 74.5 kg Carton Dimensions (W x H x D) 1,870 x 1,264 x 285 mm(with pallet)
Packed Weight 94 kg VESA™ Standard Mount Interface 600 x 400 mm
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10 % to 80 %
POWER CONSUMPTION
Typ. = 240 W Smart Energy Saving = 170 W
STANDARD(CERTIFICATION)
Safety UL / cUL / CB / TUV / KC EMC FCC Class “A” / CE / KCC
SOFTWARE COMPATIBILITY
Content Management Software SuperSign Premium Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (include battery 2ea), Power Cord, QSG, HDMI (3M), Regulation Book, Phone to RS232C Gender, Touch Pen (2ea), Touch Pen Tip (1ea) Optional OPS Kit (KT-OPSA), Wall Mount(LSW640A/B)
TOUCH
Touch type P-Cap(Ag Metal Mesh) Available object size for touch more than Ø 6 mm
Accuracy 2 mm Interface USB 2.0
Protection Glass Thickness 4T (Anti-Glare) Multi touch point Max. 40 Points
Brightness: 500 cd/?
Touch Type: P-Cap(Ag Metal Mesh)
Touch Point: Max. 40 points
Interface: HDMI (3), DP, DVI, RGB, RS232C, RJ45, USB (2), OPS USB, Touch USB (2), Wi-Fi Built-in
PANEL
Screen Size 65” Native Resolution 3,840 x 2,160 (UHD)
Brightness (Module, cd/?) 500
CONNECTIVITY
Input HDMI (3), DP, DVI-D, RGB, Audio in, USB 3.0, USB 2.0, OPS USB 2.0 Output Touch USB 2.0 (2)
External Control RS232C in/out, RJ45 in
PHYSICAL SPECIFICATION
Bezel Width 41.6 mm(T/L/R/B) Monitor Dimension (W x H x D) 1,732.8 x 1011.1 x 69.7 mm (w/o Handle)
Weight (Head) 74.5 kg Carton Dimensions (W x H x D) 1,870 x 1,264 x 285 mm(with pallet)
Packed Weight 94 kg VESA™ Standard Mount Interface 600 x 400 mm
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10 % to 80 %
POWER CONSUMPTION
Typ. = 240 W Smart Energy Saving = 170 W
STANDARD(CERTIFICATION)
Safety UL / cUL / CB / TUV / KC EMC FCC Class “A” / CE / KCC
SOFTWARE COMPATIBILITY
Content Management Software SuperSign Premium Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (include battery 2ea), Power Cord, QSG, HDMI (3M), Regulation Book, Phone to RS232C Gender, Touch Pen (2ea), Touch Pen Tip (1ea) Optional OPS Kit (KT-OPSA), Wall Mount(LSW640A/B)
TOUCH
Touch type P-Cap(Ag Metal Mesh) Available object size for touch more than Ø 6 mm
Accuracy 2 mm Interface USB 2.0
Protection Glass Thickness 4T (Anti-Glare) Multi touch point Max. 40 Points
Brightness: 500 cd/?
Touch Type: P-Cap(Ag Metal Mesh)
Touch Point: Max. 40 points
Interface: HDMI (3), DP, DVI, RGB, RS232C, RJ45, USB (2), OPS USB, Touch USB (2), Wi-Fi Built-in
PANEL
Screen Size 55” Native Resolution 3,840 x 2,160 (UHD)
Brightness (Module, cd/?) 500
CONNECTIVITY
Input HDMI (3), DP, DVI-D, RGB, Audio in, USB 3.0, USB 2.0, OPS USB 2.0 Output Touch USB 2.0 (2)
External Control RS232C in/out, RJ45 in
PHYSICAL SPECIFICATION
Bezel Width 41.6 mm(T/L/R/B) Monitor Dimension (W x H x D) 1,732.8 x 1011.1 x 69.7 mm (w/o Handle)
Weight (Head) 74.5 kg Carton Dimensions (W x H x D) 1,870 x 1,264 x 285 mm(with pallet)
Packed Weight 94 kg VESA™ Standard Mount Interface 600 x 400 mm
ENVIRONMENT CONDITIONS
Operation Temperature 0°C to 40°C Operation Humidity 10 % to 80 %
POWER CONSUMPTION
Typ. = 240 W Smart Energy Saving = 170 W
STANDARD(CERTIFICATION)
Safety UL / cUL / CB / TUV / KC EMC FCC Class “A” / CE / KCC
SOFTWARE COMPATIBILITY
Content Management Software SuperSign Premium Control and Monitoring Software SuperSign Link
ACCESSORY
Basic Remote Controller (include battery 2ea), Power Cord, QSG, HDMI (3M), Regulation Book, Phone to RS232C Gender, Touch Pen (2ea),
Touch Pen Tip (1ea) Optional OPS Kit (KT-OPSA), Wall Mount(LSW640A/B)
TOUCH
Touch type P-Cap(Ag Metal Mesh) Available object size for touch more than Ø 6 mm
Accuracy 2 mm Interface USB 2.0
Protection Glass Thickness 4T (Anti-Glare) Multi touch point Max. 40 Points
LG 'IR Spread' based
Windows XP (1Point) / Windows 7 (10 Point)
Protection Glass
Anti-Glare
IWB S/W
PANEL
Screen Size 165.10cm (65) Resolution 3,840 x 2,160 (UHD)
Brightness 350nits Back Light Type Direct
CONNECTIVITY - INPUT
HDMI Yes (3) DP No
DVI-D No Analog (RGB) Yes (1)
Analog (Component) No External Control (RS232C IN) Yes (1)
Audio Yes (1) External Control (LAN) Yes (1)
External Control (IR/Light sensor) X (Internal) External Control (Pixel Sensor) No
External Control (Pentray Control) Yes (1) USB USB 3.0 O(3) USB 2.0 O(3) (Front : 2ea, Bottom side *1 Only for software update),
Touch Out (USB 2.0, B Type) O(2)
CONNECTIVITY - OUTPUT
HDMI Yes (1) Audio Out Yes (1)
External Coaxial/Optical Output - O(1) External Control (RS232C OUT) No
POWER
Power Consumption (Typ. / Max.) 145W / 275W
STANDARD(CERTIFICATION)
Safety CB / NRTL ErP / Energy Star Yes(EU Only) / No
MEDIA PLAYER COMPATIBILITY
External Media player Attatchable No
SOFTWARE COMPATIBILITY
SuperSign-w lite No SuperSign-c No
ACCESSORY
Basic Power Cord, Remote Controller (include battery 2ea ), IR/Light sensor receiver, USB 2.0 Cable, HDMI 2.0 Cable, DisplayPort Cable, Cable Tie (2ea),
Touch Pen (2ea), PenTray (1ea), Eye-Bolt Assy (2ea), Screw Package, ESG Optional Media Player: MP700/MP500, External Speaker: SP-2100, Pen Tray: KT-WT1 (TBD)
Click To Call
